While Simmons makes every effort to provide the highest quality products, metal shavings and/or burrs occasionally remain as a by-product
of the manufacturing process. To avoid injury, please use caution when adjusting clamps, or when working with pipe and screw ends.
Inside this package
Before assembly, please check that all the items listed below are present.
Drum Rack Components
Left
Left Center
Right Center
rack assembly
1. Remove all preassembled tubing with clamps
from packaging.
2. Each T-Fitting and tube end-fitting is labeled with
a number. Lay the vertical and horizontal tubes
on the floor with the numbers matching.
The first name in electronic drums.
ASSEMBLY INSTRUCTIONS
CAUTION!
Sound Module/Hi-Hat Tube
Right
1
Tom Pad
Tube, Center
Tom Pad
Tube, Right
4
3
2
7
Please note the numbers stamped on each
tube-end and tube-fitting
Snare Drum
Pad Tube
L–Rods for Pads x5
5
6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simmons SRKHX1
Summary of Contents for Simmons SRKHX1
-
Page 1: Assembly Instructions
CAUTION! While Simmons makes every effort to provide the highest quality products, metal shavings and/or burrs occasionally remain as a by-product of the manufacturing process. To avoid injury, please use caution when adjusting clamps, or when working with pipe and screw ends. - Page 2 SD1 500 ELECTRONIC DRUM KIT ASSEMBLY SHEET rack assembly CONTINUED Match Numbers 3. There is a Drum Key Fastener location on the end of each 4. Begin with T-fitting/tube end number and insert into the fitting. Back this fastener out until the pointed end is no longer corresponding left vertical leg.
