Safety
1.
Use extreme caution when the laser beam is ON
2.
Do not point the beam toward anyone's eye
3.
Be careful not to let the beam strike the eye from a reflective surface.
4.
Do not use the laser near explosive gases or in other potentially explosive areas
Specifications
General Specifications
Circuit
Time base
Display
Measurement range
Accuracy
Resolution
Laser light source
Detecting Distance
Memory
Operating Conditions 32 °F to 122 °F (0 °C to 50 °C); RH 80% Max
Power Supply
Power Consumption
Weight
Size
Accessories
Custom LSI microprocessor circuit
Quartz crystal 4.194 MHz
5 digit, 0.4" (10mm) LCD display with function indicators
5 to 99,999 RPM
+(0.05% reading + 1 digit)
0.1 RPM (<1000 RPM); 1 (>1000 RPM)
Less than 1mW; Class 2 red laser diode (645nm approx.)
2 to 79" (50 to 2000 mm) with 10mm reflective tape and 1800rpm
(ambient light, tape size and RPM will effect maximum distance)
Last reading and MIN/MAX readings
4 x 1.5 V AA (UM 3) batteries
20mA DC approx.
0.55 lbs. (250g) including battery)
7.5 x 2.8 x 1.5" (190 x 72 x 37 mm)
4- 1.5V batteries, reflective tape 24" [600mm], and carrying case
