- Page 1 D5PSW Protection Switch User Manual May 6, 2005 P/N 101663 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - FAX 781.665.0780 - TestEquipmentDepot.com...
-
Page 2: Block Diagram
A LED indicator is Green if both Primary and Secondary are present, flashing green if the Primary is present but the Secondary is not present, and Orange if the Secondary is present but the Primary is not. The D5PSW has 3 SDI outputs. Features •... -
Page 3: Specifications
D5PSW, Side View Installation Typically, D5PSW installation consists of the following: 1. disconnect +5-18VDC from the convertor 2. connect video equipment to the BNCs 3. apply +5-18VDC power to the converter (AJA power supply model DWP) Specifications Item Specification Formats...
