Summary of Contents for Keller HPX
- Page 1 Operating instructions for the high pressure calibrator (HPX)
-
Page 2: Table Of Contents
2. General safety warnings 3. Operating the HPX calibrator 4. Description of the functions 5. Menu navigation for calibrators 6. Commissioning 7. Maintenance / disposal 8. Software for calibrators Technical data Spare parts and accessories for KELLER pressure calibrators Declaration of conformity... -
Page 3: View
View 1 10 Port for interface cable (K-104A or K-114A) (PC connection / RS485) Device base Display SELECT and ENTER buttons Oil chamber Recirculation pipe Screwed sealing plug Manual booster pump Pressure connection for test object, without overpressure valve (700 bar) Drain valve Screw compressor... -
Page 4: Notes On The Operating Instructions
If you have any problems or questions, please contact your supplier The high pressure calibrator (HPX) IMPORTANT! consult KELLER directly. may only be used to generate pres- Nothing must adhere to the surface of sure with the type HLP 22 BP hydrau- the test object (no oil, grease, water, lic oil that is supplied with the product. -
Page 5: Operating The Hpx Calibrator
Shows the peak and trough pressure values measured thus far. they are damaged or faulty. (Display is shown with reduced resolution) 3. Operating the HPX calibrator Leak measurement Leak mode is used to determine the pressure change over a defined period, which can be Operating the high pressure calibrator changed. -
Page 6: Menu Navigation For Calibrators
SELECT button ENTER button The SELECT button positioned on the The ENTER button positioned on front is used to switch the device on, the front is used to activate the se- to select a function and to select the lected function or pressure unit on the various pressure units. -
Page 7: Maintenance / Disposal
KELLER change the oil. The entire that has now elapsed [mm:ss] and the : Disables the automatic Cont system is cleaned at the same time. pressure change measured thus far. -
Page 8: Software For Calibrators
K-104 / K-114 (the software CD is included in the scope of delivery, K-114A, or can be downloaded free of charge at www.keller-druck.com) Settings on the high pressure calibrator with the ManoConfig software Device settings such as the leak... -
Page 9: Technical Data
Technical data Pressure range (FS) 0…700 bar (others on request) Overpressure 840 bar Accuracy, error band (10…40 °C) < 0,05 %FS Accuracy, error band (0…50 °C) < 0,1 %FS Leak rate* 700 bar: -2 bar @ 10 min. Display resolution 1 mbar Number of digits on display 5 digits... -
Page 10: Spare Parts And Accessories For Keller Pressure Calibrators
Spare parts and accessories for KELLER pressure calibrators suitable for Description Article number Illustration Carrying case, empty 309025.0005 Battery, type CR2430 557005.0001 Hose nipple 508832.0005 Connecting nipple, G 1/4” 508832.0004 including sealing ring Y-coupler 307025.0001 Test object adapter, 506810.0028 G 1/4”M-G 3/8”F Test object adapter, 506810.0013... -
Page 11: Declaration Of Conformity
La présente déclaration est fournie für den Hersteller: facturer pour le fabricant KELLER AG für Druckmesstechnik, St. Gallerstrasse 119, CH-8404 Winterthur in full responsibility by abgegeben durch die KELLER GmbH, Schwarzwaldstrasse 17, D-79798 Jestetten Jestetten, 4. Oktober | October | Octobre 2012 Hannes W. - Page 12 KELLER AG für Druckmesstechnik St. Gallerstrasse 119 • CH-8404 Winterthur Tel. +41 (0)52 235 25 25 • Fax +41 (0)52 235 25 00 www.keller-druck.com November • November • Novembre 2012...
