Once a volume has a LUN and is attached to a target, it is accessible to iSCSI
initiators. Each initiator can access, read and write into the volume.

Identities

To allow selective iSCSI initiator access to iSCSI target volumes, the V-
Switch uses identities to define pools of initiators. An identity is a user-
defined list of iSCSI initiators. An identity can contain from one to multiple
initiators, with each initiator having a unique WWUI.
In Figure 54, there are four iSCSI initiators in Identity A: WWUI 1, 2,5 and
8.
Chapter 7: Volume Exposure and Security
V-Switch
iSCSI Target 1
iSCSI Target 2
wwui1
Vol 1
LU0
Figure 53.
wwui1
wwui2
wwui3
wwui4
wwui5
wwui6
wwui7
wwui8
wwui9
wwui10
Figure 54.
wwui2
Vol 2 Vol 3
LU0 LU0
iSCSI Target Access
Ident A
Identity A's iSCSI Initiators
iSCSI Target 3
wwui3
Vol 4
LU1
