Basic System Cabling - Edax Element User Manual

J4 J6
5

BASIC SYSTEM CABLING

Monitor
100-240V
MAINS
100-240V
MAINS
DVI
USB Port
EDAX PC
USB Port
Dual Port NIC
(PCIe)
2735.171.31099
IP 192.168.0.101
IP ###.###.###.###
SYNC
(panel)
5335.007.31700
Cable 4035.008.11270
SG-3
(PCIe)
5335.007.31400
100-240V
MAINS
100-240V
MAINS
For
Touchscreen
IEC 2435.072.44052R or
US 2435.072.44053R
USB Cable 2735.171.31153
Ethernet cable 2435.072.44045R
Ethernet cable
Sync cable 4035.008.10900
Ferrite
Beam Control Interface cable – Microscope Model Dependent – 4035.008.#####
Printer
Figure 4 - Typical System Connections
Element Basic User Guide
5 V Power
Supply
2735.075.31149R
5V
5V Power
DPP Box
4035.008.11340
4035.075.00990
50 Ω BNC Signal
IP 192.168.0.100
2735.171.30915
For Column control
and/or Network
SEM PC
IP ###.###.###.###
Ground Cable Kit 4035.075.00920
(optional)
Page 18 of 21
Basic System Cabling
Element Microscope
Detector
