Madeli Savona Specification & Installation Manual

Functional Elegance
Savona - 24"
Features
• Free standing 24" vanity : 33-7/16"(850mm)H x 18-1/16"(458mm)D x
23-1/2" (596mm)W
• Furniture grade plywood layered with solid wood veneer and protected
with several coats of polyurethane.
• Matching nish inside out
• Two soft-close doors
• Interior bottom drawer with full extension soft-close European hardware
• Handles and legs: Polished chrome nish (Stainless steel nish optional)
Finishes
• Glossy White (GW)
• Walnut (WA)
33-7/16"
(850mm)
SIDE VIEW
33-7/16"
(850mm)
17"
(432mm)
For clari cation, please contact Madeli Customer Care at (800)-819-6988 or (305)-718-8817 Ext. 1
All dimensions are approximate and subject to standard tolerance. Speci cations subject to change without prior notice.
18-1/16"
23-1/2"
(458mm)
(596mm)
Drawer Clearance
3-1/8"
(80mm)
13"
3/8"
(330mm)
(10mm)
Madeli, USA LLC | 9710 NW 110th Ave., Suite 1
Tel: 305-718-8817 | Fax: 305-718-8477
Speci cation & Installation Guide
Top/Basin options
• White or soft Grey Quartzstone™ top & white under mount
ceramic basin
• Glossy White X-Stone top/basin
• Ceramic basin
• Tempered glass top/basin
• Glossy or Matte White X-Stone at top
• Glossy White or Walnut wood countertop
Package Dimension
26" x 21" x 36"
Gross Weight
69 lbs / 31.36 kgs
18-1/16"
(458mm)
17-5/16"
11/16"
(440mm)
(18mm)
| Miami , FL 33178 | madeli.com
| Toll Free: 1-800-819-6988
Model Number
B925-24-001-XX
01 | Page
Rev. 052715
All Rights Reserved - 2014
