- Page 1 USER INSTRUCTIONS www.cleanspacetechnology.com CleanSpace2 Powered Respirator USA – English TC-21C-1065 www.cleanspacetechnology.com Important! Before use, the wearer must read and understand these user instructions. Keep these user instructions for reference.
-
Page 2: Table Of Contents
Product and Accessory information ........................30 Product Warranty ............................... 31 ™ Read these instructions in conjunction with the appropriate CleanSpace filters and accessories instructions. WARNING This product is part of a system that helps protect against certain airborne contaminants. Misuse may result in sickness or death. -
Page 3: System Description
For proper use, see your Occupational Health Specialist, these user instructions or contact PAFtec Customer Service on 1 888 804 0038 No PAPR can fully protect you if you are not clean shaven. CleanSpace2 is not suitable for users with facial hair. -
Page 4: Niosh - Approval, Cautions And Limitations
Misuse of CleanSpace2 by cleaning the filter may result in overexposure to contaminants and lead to sickness or death. You must recalibrate the internal pressure sensor any time that your CleanSpace2 is exposed to changes in temperature of more than 36°F (20°C). -
Page 5: S - Special Or Critical User Instructions
6. S - Special or Critical User Instructions This respirator contains a system for synchronising with your breathing and regulating mask pressure. This system requires re-calibration whenever it experiences a change in temperature of more than 36°F (20°C). It is best practice to also re-calibrate if the unit has been in storage, particularly if the storage temperature is not known. -
Page 6: Respirator Program Management
Do not disassemble the respirator case. There are no user serviceable parts inside. Failure to follow all instructions on the use of this product, and/or failure to use the respirator during times of exposure, may lead to adverse effects on the wearer’s health and may render the warranty void. WARNING This product is part of a system that helps protect against certain airborne contaminants. -
Page 7: System Components
9. System Components Figure 1 - System Components... - Page 8 PARTS OF THE RESPIRATOR Your respirator can be used with either a standard filter (PAF-1102 / PAF-1103) or with a high capacity filter (PAF- 1003). The high capacity filter is used with a filter adaptor (PAF-0038) and both standard filters are used with a filter cover (PAF-1095).
-
Page 9: Controls And Indicators
This button is used to check that the respirator is able to deliver its minimum designed flow. Pressing it once, when the CleanSpace2 is in Standby Mode (not ON Mode), starts the flow test which lasts about 5 seconds. See Section 12 for instructions on running the flow test. -
Page 10: Mask Fitting
FILTER WARNING ALARM CleanSpace2™ has a Filter Warning Alarm, which is triggered when the filter is blocked. If the Filter Warning Alarm sounds (two beeps, repeated once per second) or the Filter Warning Alarm light comes on, you must move out of the contaminated area, and change the filter. -
Page 11: Using Cleanspace2
DO NOT USE COMPRESSED AIR OR A BRUSH TO CLEAN THE FILTER! HEPA FILTERS ARE VERY EASILY DAMAGED BY THE USE OF COMPRESSED AIR OR BY BRUSHING. Misuse of CleanSpace2 by cleaning the filter may result in overexposure to contaminants and lead to sickness or death ... - Page 12 STEP 2 – CALIBRATE This respirator contains a system for synchronising with your breathing and regulating mask pressure. This system requires re-calibration whenever it experiences a change in temperature of more than 36°F (20°C). It is best practice to also re-calibrate if the unit has been in storage, particularly if the storage temperature is not known.
- Page 13 These sizes should be recorded in this manual (see Section 11 above). Fit a mask to CleanSpace2 Examine the mask AirClips. One is open and one is closed. Find the one that is closed. Seen from above it is on the right hand side. See Figure 4 Locate the right hand blower AirClip.
- Page 14 Figure 7 - Mask on Blower (Note - connection is on Figure 6 - Join AirClip right hand side) Check that the mask is the right way up! The pointed, nose section of the mask must face up, in the same direction as the keypad. See Figure 8. Figure 8 - Nose section of mask and keypad must both face up Leave the other mask arm and bellow free until you are fitting the Respirator.
- Page 15 Fit the Harness Locate the strap on the harness that is made from loop-pile material. . This is the back strap. If a neck pad is in place, remove it by pulling it away from the two strips of loop pile fabric on the blower.
- Page 16 Press neck pad into place against these strips Figure 12 - Fitting neck pad Make sure to fit the same size neck pad as you used in your last successful quantitative fit test. The size (thick or thin) should be recorded in the table in Section ...
- Page 17 Figure 14 - Blower behind neck Figure 15 - Left hand on mask, Figure 16 - Mask on face, harness right on harness on head Figure 18 - AirClip Figure 17 - Fasten AirClip Figure 19 - Settle harness Breathe normally. The motor should start and you should feel fresh air on your face. If the motor does not start, it was not in Standby Mode.
- Page 18 STEP 5 – CHECK MASK SEAL It is essential to do a fit check every time you wear a CleanSpace2 Locate PAF-1009, the red Seal Check Cap. Fit Seal Check Cap over the exhalation valve in the mask. The Cap should snap into place.
-
Page 19: Entering And Exiting The Contaminated Area
Using your fingers, feel around the perimeter of the mask for leaks. You will feel any leak as a cool flow of air over your finger. For greater sensitivity breathe out firmly to raise the mask pressure. Wetting your fingers will make it easier to feel tiny leaks. -
Page 20: Working In Noisy Environments
14. Working in Noisy Environments In most noisy environments the CleanSpace2 alarms are still clearly audible to the wearer. But if there is a chance that you will not hear the alarms, you must take the following extra precautions ... -
Page 21: Fitting & Changing The Filter
BLOCKED FILTER ALARM All CleanSpace respirators have a Filter Blocked alarm, which is triggered when the filter requires replacement (2 beeps, repeated every second). If the blocked filter alarm is triggered (2 beeps, repeated every second, red LED flashes), leave the contaminated area immediately and replace the filter. - Page 22 To unlock the filter cover, lift the pin located on the end of the filter cover. The filter cover will swing open exposing the used filter. Remove the filter. Check that the area where the filter sits is clean. If necessary wipe it with a clean cloth or CleanSpace Cleaning Wipe.
- Page 23 Figure 27 - Fitting a new HEPA Filter ™ Use only NIOSH-approved CleanSpace filters with the respirator. If used with other filters CleanSpace2 is not NIOSH approved. Use of other filters may result in overexposure to contaminants and lead to sickness or death.
- Page 24 WHEN FITTING A NEW FILTER THE BLOCKED FILTER ALARM SHALL BE TESTED BEFORE THE RESPIRATOR IS PUT BACK INTO SERVICE. SEE “TESTING THE BLOCKED FILTER ALARM” AT THE END OF THIS SECTION TESTING THE BLOCKED FILTER ALARM After changing the filter, check that the Blocked Filter Alarm is audible and the Filter LED is working. Do not fit the Flow Test Cap for this test.
-
Page 25: Battery Information
16. Battery Information CleanSpace2 is not intrinsically safe. Do not use in flammable or explosive atmospheres. Doing so may result in injury or death. Always correctly use and maintain the internal lithium ion battery packs. Failure to do so may result in fire or explosion or could adversely affect respirator performance and result in injury, sickness or death. - Page 26 Li-ion cells. The soft packaging allows the cells to expand slightly under extreme heat, making them safer in fault conditions. CleanSpace respirators use quality Li-ion polymer batteries and are designed to be viable over a minimum of 500 complete charge and discharge cycles while still maintaining at least 70% of their specified full capacity.
-
Page 27: Cleaning
We recommended that you clean your respirator after every use. The mask, blower, neck pad and harness need to be cleaned separately. Disassemble the mask, neck pad and harness from the blower before cleaning. CleanSpace Cleaning Wipes are recommended as a simple and effective method of cleaning the blower and masks. -
Page 28: Periodic Maintenance & Checking
Use a gentle brush to remove any dirt, grit or fibres from the Velcro attached to the blower. Using CleanSpace Cleaning Wipes, wipe down the outside of the blower. The blower can also be cleaned with a damp cloth. -
Page 29: Specifications
19. Specifications Air Flow Greater than 115 litre/minute Breath-responsive, with max inflow to mask 115 – 200 litre per minute, dependant on altitude, filter and battery condition. Operating 14°F to 113°F (-10°C to 45°C) Temperature Range The motor will shut down while the temperature of the battery pack is above 140°F (60°C) or below 14°F (-10°C) Operating Zero to 90%, non-condensing... -
Page 30: Product And Accessory Information
Harness and PAF-0016 Neck Pad Thin: 18.3 oz. (520 gram) Masks: 4.2 to 5.3 oz. (120 to 150 gram) Intrinsic CleanSpace2 is not an intrinsically safe system Safety 20. Product and Accessory information Refer to the NIOSH approval matrix for approved combinations... -
Page 31: Product Warranty
21. Product Warranty This product has been manufactured using quality parts and processes. PAFtec Australia Pty Ltd warrants that the product is free from defective workmanship and parts for a period of one (1) year from the date of original purchase provided the product has been used, cleaned and maintained in accordance with these instructions and PAFtec’s recommendations. - Page 32 PAFtec Australia Pty Ltd ABN 24 146 453 554 Ground Floor, 16-18 Carlotta Street, Artarmon NSW 2064 Australia T: 1 888 804 0038 |E: support@cleanspacetechnology.com S005-7160 Rev 8, 25 SEPT 2017 Released on Change Note ECN0905...
