50 Bearfoot Road
Northborough, MA 01532
www.solmetex.com
Solmetex Warranty
Solmetex Hg5® Air Water Separators are warranted against defects in material and workmanship for a period of two (2) years from the
date of purchase, established by proof of purchase or formal warranty registration. During the warranty period Solmetex will at its option
repair or replace products that prove to be defective.
Solmetex Hg5® Collection Containers are warranted against defects in material and workmanship for a period of one (1) year from the date
of purchase, established by proof of purchase or formal warranty registration. During the warranty period Solmetex will at its option repair
or replace products that prove to be defective.
Labor, transportation and service charges are not included.
Limitations of Warranty
The warranty shall not apply to defects resulting from improper installation, maintenance, abuse, unauthorized modification, or operation
outside of the environmental specifications for the product or damages that occur due to improper repackaging of equipment for return to
SolmeteX.
USE OF LINE CLEANERS HAVING A pH LESS THAN 6 OR GREATER THAN 8 WILL VOID THESE WARRANTIES.
For a complete list of recommended cleaners, visit our web site www.solmetex.com.
No other warranty is expressed or implied. SolmeteX specifically disclaims the implied warranties of merchantability and fitness for
particular purpose.
Exclusive Remedies
The remedies provided herein are the buyer's sole and exclusive remedies. SolmeteX shall not be liable for any direct, indirect, special,
incidental or consequential damages, whether based on contract, tort or any other legal theory.
Hg5® Manu al (Canada)
Solmetex Hg5® Amalgam Separator
Type 2 – Maximum Flow = 1000 ml/min
Installation and Maintenance Instructions
Warnings and Warranty ...................... Page 1
Set-Up ........................................ Page 2
Installation .................................... Page 3
Installation Examples ......................... Page 4
Maintenance........................... ........ Page 4
Collection Container Replacement ............ Page 5
Service & Parts ............................... Page 7
Thoroughly read and understand instructions prior to installing, operating and
servicing the Hg5® Amalgam Separator.
The waste stream treated by the Solmetex Hg5® is generated by a dental vacuum
system and as such may contain concentrations of solid and soluble mercury and
silver. Because of this, any spills should be considered hazardous and should be
handled in accordance with standard hazardous materials (HAZMAT) handling
procedures.
Full Collection Containers are a HAZMAT and should be handled, stored and
disposed of according to regulations applying to hazardous waste containing
mercury. Always wear protective gear when handling full Solmetex Hg5® collection
containers (latex gloves, safety glasses or face shield) and dispose of per local
regulations and codes.
(Canada)
Table of Contents
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for Solmetex Hg5
Summary of Contents for Solmetex Hg5
- Page 1 Solmetex Warranty Solmetex Hg5® Air Water Separators are warranted against defects in material and workmanship for a period of two (2) years from the date of purchase, established by proof of purchase or formal warranty registration. During the warranty period Solmetex will at its option repair or replace products that prove to be defective.
-
Page 2: Set-Up
Hg5® Amalgam Separator – Initial Set-Up A. Engage slot on pin (see detail). Rotate assembly into place (keeping slot engaged on Note: The Hg5® may be installed “right pin). Push top bracket down over tabs until handed” as seen below or “left handed”... -
Page 3: Installation
11” W x 29” H x 8” D Pump Inlet DO NOT connect Hg5® to One Hg5® will serve up to five doctors. outlet of the water ring pump. Minimize water lift height. Maximum Temperature = 120 F (52 ... -
Page 4: Installation Examples
WITH DENTAL VACUUM SYSTEMS: Follow manufacturers instructions. Note: Plan to rinse no more than 4 rooms every 10 minutes. Limit rinsing to 1.5 liters per room. Rinsing too much or too rapidly can overfill the Hg5® and could affect the unit’s efficiency. -
Page 5: Collection Container Replacement
(Canada) Warning The waste stream treated by the Hg5® is discharge from a dental vacuum system and as such may contain concentrations of solid and soluble mercury and silver. Because of this any spills should be considered hazardous and should be handled in accordance with standard hazardous materials (HAZMAT) handling procedures. Full Collection Containers are a HAZMAT and should be handled, stored and disposed of according to regulations applying to hazardous waste containing mercury. - Page 6 3. With the vacuum system still running, remove the ® full collection container from the Hg5 Unit as follows: a. Open the slider lock bag (supplied) and slip it over the collection container to be removed. b. Support the collection container with one hand, removing the retaining pins with the other hand.
-
Page 7: Service & Parts
Hg5® Service & Parts SERVICE The Hg5® is designed to provide years of trouble-free service, with minimal attention. In the unlikely event of system related problems, please consult the troubleshooting and maintenance chart below. Problem: Little or No vacuum at the hand piece Check sediment level of collection container, if full change the collection container.
