Solmetex Hg5
Maximum Flow 2000 ml/min Maximum Fillable Volume 1900 ml
Installation and Maintenance Instructions
Thoroughly read and understand instructions prior to installing,
operating and servicing the Hg5®HV Amalgam Separator. These
instructions are also available on our website at www.solmetex.com.

Table of Contents

Installation ........................... Page 2
Installation Diagram .......... Page 3
Maintenance ...................... Page 4
Service ................................ Page 5
The waste stream
treated by the
Solmetex Hg5®HV is
generated by a dental vacuum
system and as such may contain
concentrations of solid and
soluble mercury and silver.
Because of this, any spills should
be considered hazardous and
should be handled in accordance
with standard hazardous
materials (HAZMAT) handling
procedures.
Full Collection Containers
are a HAZMAT and should be
handled, stored and disposed of
according to regulations applying
to hazardous waste containing
mercury. Always wear protective
gear when handling full Solmetex
Hg5®HV collection containers
(latex gloves, safety glasses or
face shield) and dispose of per
local regulations and codes.
Hg5®-HV Manual - July 2017
HV Amalgam Separator
®
Solmetex Warranty
Solmetex Hg5®HV Air Water Separators are warranted against defects in material and
workmanship for a period of two (2) years from the date of purchase, established by proof
of purchase or formal warranty registration. During the warranty period Solmetex will at its
option repair or replace products that prove to be defective.
Solmetex Hg5®HV Collection Containers are warranted against defects in material and
workmanship for a period of one (1) year from the date of purchase, established by proof
of purchase or formal warranty registration. During the warranty period Solmetex will at its
option repair or replace products that prove to be defective.
Labor, transportation and service charges are not included.
Limitations of Warranty
The warranty shall not apply to defects resulting from improper installation, maintenance,
abuse, unauthorized modification, or operation outside of the environmental specifications
for the product or damages that occur due to improper repackaging of equipment for return
to Solmetex.
USE OF THIRD PARTY COLLECTION CONTAINERS OR LINE CLEANERS HAVING A pH
LESS THAN 6 OR GREATER THAN 8 WILL VOID THESE WARRANTIES. For a complete list of
recommended cleaners, visit our web site www.solmetex.com.
No other warranty is expressed or implied. Solmetex specifically disclaims the implied war-
ranties of merchantability and fitness for particular purpose.
Exclusive Remedies
The remedies provided herein are the buyer's sole and exclusive remedies. Solmetex shall
not be liable for any direct, indirect, special, incidental or consequential damages, whether
based on contract, tort or any other legal theory.
www.solmetex.com
800-216-5505

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hg5 and is the answer not in the manual?

Questions and answers

Related Manuals for Solmetex Hg5

Summary of Contents for Solmetex Hg5

  • Page 1: Table Of Contents

    (2) years from the date of purchase, established by proof concentrations of solid and of purchase or formal warranty registration. During the warranty period Solmetex will at its soluble mercury and silver. option repair or replace products that prove to be defective.

  • Page 2: Installation

    • The unit is piped into the vacuum line between the treatment rooms and the vacuum source. The line from the treatment rooms is piped to the inlet of the Hg5®HV and the outlet is piped to the vacuum source. DO NOT connect the unit to the outlet of the separating tank (dry vacuum system) or water ring pump (wet vacuum system).

  • Page 3: Installation Diagram

    Hg5-HV Inlet Separating Tank DO NOT connect Hg5-HV to outlet of tank. Hg5-HV Outlet NOTE: The Hg5 HV should be installed so that the outlet of the Hg5 HV Any Water DO NOT connect Hg5 HV to Pump Inlet Ring Pump outlet of the water ring pump.

  • Page 4: Maintenance

    WITH DENTAL VACUUM SYSTEMS: Follow manufacturers instructions. Note: Plan to rinse no more than 5 chairs every 10 minutes. Limit the total maximum flow to the Hg5® during rinsing to 1 liter per minute. Rinsing too much or too rapidly can overfill the Hg5® and could affect the unit’s efficiency.

  • Page 5: Service

    1. Check sediment level of collection container, if full change collection container. 2. Check the pH of vacuum line cleaner, if below 6 or above 8 change collection container and line cleaner. Visit www.solmetex.com for a recommended list of cleaners.
