Installation
GUIDE
VDWU524SS
VDWU524WSSS
FDWU524WS
FDWU524
VDWU324SS
FDWU324

Advertisement

Table of Contents
loading

Summary of Contents for Viking VDWU524SS

  • Page 1 Installation GUIDE VDWU524SS VDWU524WSSS FDWU524WS FDWU524 VDWU324SS FDWU324...
  • Page 2: Table Of Contents

    To prevent accidents, which could cause serious injury or death, as well as machine damage read these instructions before installation and / or use. INTRODUCTION 1. IMPORTANT SAFETY INSTRUCTIONS 1.1 INSPECT THE DISHWASHER 2. TOOLS WHICH MAY BE NEEDED 3. MATERIALS WHICH MAY BE NEEDED 4.
  • Page 3: Introduction

    user. INTRODUCTION WARNING Please read this installation manual and particularly the safety instructions When installing the dishwasher, follow completely and carefully. They will save you basic precautions, including the time and effort and help to ensure optimum following: dishwasher performance. •...
  • Page 4: Inspect The Dishwasher

    and replace parts as necessary. electrical overload. The dishwasher is designed for an electrical supply of 120 V 1.1 INSPECT THE DISHWASHER (volts), 60 Hz (hertz), AC, connected to a After unpacking the dishwasher and prior to installation, thoroughly inspect the dishwasher-dedicated, properly grounded dishwasher for possible freight or cosmetic electrical circuit with a fuse or breakers...
  • Page 5: Tools Which May Be Needed

    2. TOOLS WHICH MAY BE NEEDED Flat head Screwdriver 3. MATERIALS WHICH MAY BE NEEDED (Additional materials may be required to comply with local codes) Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line. Elbow with 3/4”...
  • Page 6: Materials Supplied

    4. MATERIALS SUPPLIED 4.1 PARTS SUPPLIED 4.4 DISHWASHER Parts for your dishwasher will PARTS BAG 2 come in several plastic bags. (SELECT MODELS) Check your parts bags shown In addition to the manual bag to make sure you have all the and the dishwasher parts bag parts as listed to the left.
  • Page 7: Dishwasher Specifications

    5. DISHWASHER SPECIFICATIONS 5.1 TECHNICAL FEATURES 4.35 - 145 psi (0.3 - 10 bars) Permissible water pressure 120 V (volts), 12 A (amps), 60Hz (hertz) Electrical connection 1400 W (watts) Total power 1100 W (watts) Heater power NOTICE : Because we continually strive to improve our products, we may change our specifications and design without prior notice.
  • Page 8: Enclosure Preparation

    6. ENCLOSURE PREPARATION 6.1 ELECTRICAL PREPARATION WARNING The dishwasher is designed for an electrical supply of 120 V, 60 Hz, AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse or breaker rated for 15 amperes. 6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS WARNING Dishwasher must be secured to adjacent cabinetry using the mounting brackets provided.
  • Page 9: Adjusting Height

    Tighten the plugs on both sides of your machine (v) Place the two mounting brackets into the top corners of the dishwasher. Fix the mounting brackets (A) to the top corners of the dishwasher, with the screws supplied. Bend sides of mounting brackets (B) in order to fix from sides (if necessary).
  • Page 10: Installing The Side Trim Strips

    NOTICE : • Make sure the dishwasher is plumb and notice dishwasher can be placed with a small clearance under the counter top. • Turning the screwdriver in the direction of the black arrows will bring the dishwasher back feet up. •...
  • Page 11: Preparing The Water Connection (A)

    6.5 PREPARING THE WATER CONNECTION (A) Install an easily accessible shut-off valve (not supplied) in the water supply line. All solder connections must be made before the water line is connected to the dishwasher’s water inlet valve. Water can also be supplied to the dishwasher by using a flexible braided hose line.
  • Page 12 NOTICE : • Either one of the methods below must be used or the dishwasher will not operate properly. • A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher.
  • Page 13: Steam Protection Foil

    6.7 STEAM PROTECTION FOIL Steam will form inside the dishwasher during operation. At the end of the cycle, when the dishwasher door is opened, it is required to use a steam protection foil to prevent any steam from collecting on the underside of the counter top. 6.6.2 FITTING THE PROTECTION FOIL Before applying the steam protection foil to the underside of the countertop, clean the area with...
  • Page 14: Placement Of Dishwasher Into The Opening

    7. PLACEMENT OF DISHWASHER INTO THE OPENING Now place the dishwasher into the opening and get ready to connect all hoses and electrical connections. CAUTION Make sure all hoses are pulled through the side opening of the cabinet, no hoses are kinked and all slack is taken out as shown in the figure.
  • Page 15 • The access hole of the supply cord to the 7.1.2 WATER SUPPLY CONNECTION Water supply may be connected to the installation compartment must be smooth dishwasher in one of two ways: and rounded and it must be large enough •...
  • Page 16: Readjusting Foot Levels

    7.2 READJUSTING FOOT LEVELS Now that the dishwasher is in the cabinet you must readjust the feet to bring the dishwasher up to the required height and attach it underneath the countertop. 1. Readjust the front foot levels with adjusting wrench to balance the dishwasher and raise it up under the countertop, make sure the unit is level.
  • Page 17 Open locking tab on the Toe Kick(p). (A) Place it on the slots, which are on the brackets fixed before, and adjust the height - max. 1½" (38 mm). (B) Close locking tab on the Toe Kick. (C)
  • Page 18: Fixing The Cabinet To The Counter

    7.4 FIXING THE CABINET TO THE COUNTER...
  • Page 19: Preparing The Custom Door

    7.5 PREPARING THE CUSTOM DOOR Mid. Point Mid. Point Weight (max) 9 Kg / 19 lbs Height (h) : Height of the wooden door 30” (760mm) Width (w) : 23 ¼” to 23 ½” (592mm - 595mm) Thickness (t) : ¾ “ (19mm) Weight (max) : 9 Kg / 19 lbs...
  • Page 20 7.6 PREPARING THE CUSTOM DOOR...
  • Page 21: Installing The Custom Door

    7.7 INSTALLING THE CUSTOM DOOR 7.8 FIXING THE CUSTOM DOOR...
  • Page 22: Fixing The Custom Door

    7.9 FIXING THE CUSTOM DOOR Ø 4 x 36mm 7.10 ADJUSTING THE KICK PLATE • Check whether the bottom of the door (A) hits the kitchen cabinet base (B) . • If the door hits the cabinet base cut the necessary section out of the base (B).
  • Page 23: Connection

    7.11 CONNECTION (1.2 cm) (1.9 cm) (1.9 cm) (1.9 cm)
  • Page 24: Installer Checklist

    8. INSTALLER CHECKLIST Notice : Your installer must have completed and • If your dishwasher is not operating checked the following: properly after following these steps: • The dishwasher is square and level. Contact your dealer to schedule an • The dishwasher is fastened securely to authorized service agent to inspect your the cabinetry.
  • Page 25 • Name of dealer from whom purchased Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-845-4641, or write to:...
  • Page 26 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our web site in the US (www.vikingrange.com) (061518) 068681-000 EN 068681-000 EN/ 16-07-18.(8:33)
