Please read these instructions carefully before assembly
dnp Supernova™
Installation guide
23-23 screen material
dnp optical front
projection screens
>
02
Remain packed until rolled out on frame
Step 9
Core
dnp denmark as
>
Phone +45 4616 5100
Skruegangen 2
Fax
+45 4616 5200
DK-2690 Karlslunde
www.dnp-screens.com
Denmark
dnp@dnp.dk
03
Warnings
Follow all assembly instructions. Incorrect assembly can
lead to screen damage and invalidate the dnp warranty.
Be careful not to kink the film during handling as it could
make permanent marks in the film.
Keep sharp objects away from the film as they can scratch
the film and destroy the optical properties.
Please note that the backside of the film is more sensitive
than the frontside and should thus be handled more care-
fully.
Do not apply pressure to the screen material once it is
mounted on the frame.
Need help?
US citizens: Contact dnp US Hotline:
Call
(714) 991-6405
for instant service- and
installation support.
Open Monday-Friday from 6:00 AM to 6:00 PM. US requests only.
All others:
Please contact place of purchase
October 2016 - Part no. 3757 - rev. 3 - dnp
04
L
01
05
