Summary of Contents for Base Line BaseStation 1000
- Page 1 BaseStation 1000 Irrigation Controller Quick Start Guide December 4, 2017 Customer Service 1-866-294-5847...
- Page 2 Baseline Inc. www.baselinesystems.com Phone 208-323-1634 FAX 208-323-1834 Toll Free 866-294-5847 ©2017 Baseline Inc. All Rights Reserved.
-
Page 3: Table Of Contents
BaseStation 1000 Quick Start Guide Table of Contents INTRODUCTION ............................1 CONTROLLER FRONT PANEL LAYOUT ....................1 ON-SCREEN HELP............................. 3 ZONE STATUS REPORT .......................... 3 Understanding Zone Statuses ..................... 3 QUICK START YOUR CONTROLLER..................... 4 STEP 1 – Install and Connect Devices ................... 4 STEP 2 –... - Page 4 BaseStation 1000 Quick Start Guide Page ii...
-
Page 5: Introduction
This quick start guide helps you get familiar with the BaseStation 1000 interface and the buttons on the front panel. It walks you through the basic steps for getting your controller configured for watering. - Page 6 BaseStation 1000 Quick Start Guide Controller Front Panel Layout Display – The display indicates the current state of the controller and is used to program the controller. Refer to Setting Up the Screen Display in the User Manual for information about improving image quality in outdoor conditions including direct sunlight and low light.
-
Page 7: On-Screen Help
BaseStation 1000 Quick Start Guide Select an option or perform an action BACK Return to a previous screen or cancel an action On-Screen Help Press the ? button at any time to display the On-Screen Help. When the help displays, press the ... -
Page 8: Quick Start Your Controller
BaseStation 1000 Quick Start Guide Quick Start Your Controller These instructions walk you through the basic steps for getting your controller configured for watering. Refer to the User Manual for complete instructions for all of the controller’s features. STEP 1 – Install and Connect Devices Install all of your irrigation devices and connect them to the controller according to the instructions that came with the devices. -
Page 9: Step 5 - Set Watering Start Conditions
BaseStation 1000 Quick Start Guide STEP 5 – Set Watering Start Conditions A program is not active until you select a start condition for it. Press the Program Setup button. Highlight the Setup Prg. Start option, and then press OK. For the initial system configuration, we recommend that you set up a Day &... -
Page 10: Step 6 - Set The Water Windows
OK button to display a checkmark in the field. When you enable the Intelligent Soak™ feature, the BaseStation 1000 uses intelligent watering algorithms that apply cycles in the optimal order to maximize water penetration and minimize evaporation loss. -
Page 11: Step 8 - Set The Controller To Run
BaseStation 1000 Quick Start Guide STEP 8 – Set the Controller to RUN Press the RUN button to put the controller in the Run menu. Watering will start when the next start day and time is reached. If you want to manually start a program, press the MANUAL RUN button. Press the button to highlight the Start/Stop Program option.
