- Page 1 PROFESSIONAL CORDLESS IMPACT SCREWDRIVER Model CIS100 Part No 4500625 OPERATING & MAINTENANCE INSTRUCTIONS GC0309...
-
Page 2: Introduction
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Table Of Contents
The CIS100 is a professional, rechargeable cordless impact screwdriver. Upon receipt, unpack and lay out the components, checking against the following list. Any damage or deficiency should be reported to your CLARKE dealer immediately. 1. 12V Impact screwdriver with 1.7a/h battery pack 2. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - do not wear loose clothing or jewellery. Tie long hair out of the way. 3. Keep children and visitors away - do not let children handle the screwdriver. -
Page 5: Safety Symbols
19. NEVER attempt any repairs yourself. If you have a problem with this product contact your local CLARKE dealer. SAFETY SYMBOLS The full technical specification of the battery charger is printed on a label on the charger. -
Page 6: Electrical Connections
3. Should you wish to replace the fuse cover, ensure that the correct replacement is used (as indicated by marking or colour code). 4. Replacement fuse covers can be obtained from your local Clarke dealer or most electrical stockists. FUSE RATING The fuse in the plug must be replaced with one of the same rating and this replacement must be ASTA approved to BS1362. -
Page 7: Component Identification
COMPONENT IDENTIFICATION Bit Holder (chuck) Battery Release Button Forward/Reverse Switch-bar Battery Pack Trigger Wrist Strap BATTERY CHARGING 1. The new battery pack will require charging before use. FIG 1 2. Squeeze the battery release buttons on either side of the battery pack and pull gently down to disengage the battery pack from the machine body as in Fig 1. - Page 8 • If the red charging light will not stay on for more than a few moments, the battery pack is likely to be defective and it must be replaced with a new one. • When the RED charging light goes out after about 1/2 hour, and the GREEN light remains on, the battery pack can be considered charged and be...
-
Page 9: Installing & Removing The Bit
INSTALLING & REMOVING THE BIT 1. Pull the sleeve away from the machine body and insert the bit into the sleeve as far as it will go. Release the sleeve to secure the bit in place as shown in Fig 3. 2. -
Page 10: Recharging
Refer to your Clarke dealer if internal maintenance is required. Your Clarke Impact Screwdriver has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local Clarke dealer. -
Page 11: Technical Specifications
TECHNICAL SPECIFICATION r t r < Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. -
Page 12: Parts List And Diagram
PARTS LIST l i v s i r... - Page 13 PARTS DIAGRAM...
-
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY... - Page 15 NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
