Airaid 302-370 Installation Instructions

R
S
Component Identification
Description
A VENT; 1/2" BARB TO QUICK
B HOSE CLAMP #6 MINI
C HOSE CLAMP #52
D HOSE; 3-1/4" ID X 2"L
E HOSE; 1/2"ID X 12"L
F VENT; STRT 1/2" HOSE, 1/4"
G GROMMET; 1" OD, 1/2" ID, 1/2"
Full color instructions can be viewed on our web site at Airaid.com. If you need any assistance please call 1-800-498-6951 to speak with
TO START:
1. Turn off the ignition and disconnect the negative
battery cable.
NOTE: Disconnecting the negative battery cable
erases pre-programmed electronic memories. Write
down all memory settings before disconnecting the
negative battery cable. Some radios will require
an anti-theft code to be entered after the battery is
reconnected. The anti-theft code is typically supplied
with your owner's manual. In the event your vehicles
anti-theft code cannot be recovered, contact an
authorized dealership to obtain your vehicles anti-
theft code.
2. Disconnect the Inlet air temperature sensor electrical
connection and loosen the hose clamp securing the
intake plenum to the throttle body.
K
O
N
Q
K
Qty. Part # Description
1 82629 H INTAKE TUBE
1 08407 I HOSE CLAMP #56
2 08610 J HOSE; 3-1/2"ID X 2-1/2"L HUMP
1 08690 K EDGE TRIM (55")
1 087031 L BOLT; M6 X 1.00" 12MM, SS
1 080022 M WASHER, M6 SPLIT LOCK ZINC
1 08064
a representative in our Customer Service Center before returning the product.
3. Disconnect the crank case vent from the intake
plenum.
4. Loosen the hose clamp securing the intake hose to the
factory air box.
Installation Instructions
For Part Numbers:
302-370
2013-18 RAM 1500
2019 RAM 1500 Classic
V6-3.6L
A
B
E
I
J
I
L
M
L
N
P
N
M
M
L
M
N
L
M
Qty. Part #
1 KIT27622TK
2 08620
1 08699
1 102480
6 07794
6 1-3025
702-466 SynthaMax Dry Media Filter - Black
NOT LEGAL FOR SALE OR USE ON ANY POLLUTION
CONTROLLED MOTOR VEHICLE IN CALIFORNIA OR
STATES ADOPTING CALIFORNIA EMISSION PROCEDURES.
See Airaid.com for CARB status on each part for a specific vehicle
F
H
C
D
C
Description
N WASHER; 6MM FLAT, SS
O HEAT SHIELD
P SCOOP
Q ADAPTER; UNIVERSAL, 6",3.5"
R HOSE CLAMP #104
S AIR FILTER
5. Lift up the intake plenum to dislodge it from the
mounting grommets and then remove the plenum from
the vehicle.
6. Lift the air box assembly off of the mounting studs
and then remove the air box from the vehicle.
NOTE: AIRAID recommends that customers do not
discard factory air intake.
G
Qty. Part #
6 08269
1 073173
1 073174
1 21512-1
1 08697
1 702-466
