Overview of Editable Parameters
Description
Operating mode
Data bits
2
Baud rate
Stop bit
Parity
Flow control
XON character
XOFF character
Terminating resistor
RS-485/422
Process data length
1) Values in brackets for EtherCAT and Modbus-TCP
2) Option 7 Bit works only in combination with a parity (even or odd)
Options
1
Disabled (0) / RS232 (1) / RS485 (2) / RS422 (3)
7 Bit (0) / 8 Bit (1)
300 (0) / 600 (1) / 1200 (2) / 2400 (3) / 4800 (4) / 9600 (5) / 14400 (6) /
19200 (7) / 28800 (8) / 38400 (9) / 57600 (10) / 115200 (11)
1 Bit (0) / 2 Bit (1)
None (0) / Even (1) / Odd (2)
None (0) / CTS/RTS (1) / XON/XOFF (2)
0 ... 255
0 ... 255
Off (0) / On (1)
16 Byte (1)
For public disclosure
RSTi-EP Slice I/O Serial Communication Module
Default
Disabled
8 Bit
9600
1 Bit
None
None
17
19
Off
16 Byte
