SPECIFICATIONS

SPECIFICATIONS of LCS-100

Beam Size
Spectral Match Classification
Beam Non-uniformity
Temporal Instability
Collimation Angle
Working Distance
Irradiance Adjustment
Light ripple:
Line regulation:
Operating Environment:
Lamp Type
Lamp Life
Input Power
Fuses:

Typical Output Power from LCS-100

Working Distance from the
output flange (inches)
TM
Solar Simulator
1.5 X 1.5 inch (38mm X 38mm)
A (IEC 60904-9 2007)
A (ASTM E927 – 10)
B (IEC 60904-9 2007)
B (ASTM E927 – 10)
B (IEC 60904-9 2007)
B (ASTM E927 -10)
< 6°
7" ± 1" ( 203 ± 51mm)
Iris: + 0% - 40%
Height: ~0.18 SUN / inch
<0.5% rms
0.03%
5°C to 40°C; <80% RH non-condensing; <3000m Altitude;
Indoor Use only; Installation Category II; Pollution degree 2
100W Ozone – Free Xenon
~1000 Hours typical
100 – 240 VAC, 50 / 60 Hz, 130W
1.5A T (slo-blo), 250V for 100 / 120 VAC
0.8A T (slo-blo), 250V for 200 / 240 VAC
TM
Readings with AM0
6
7
8
9
10
Oriel
Solar Simulator
Readings with AM1.5G
Filter (mW/cm2)
247
184
151
126
105
- 27 -
M94011A
TM
®
LCS-100 Small Area Sol1A
Filter (mW/cm2)
161
119
100
82
69
