TECHNICAL MANUAL
Of
Intel Q87 Express Chipset
Based
M/B for LGA 1150 Quad Core Ready
Intel Core Processor
NMF94RM
Rev: 1.0
Release date: March 23, 2015
Trademark:
* Specifications and Information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
Advertisement
Table of Contents
Related Manuals for IBT Technologies NMF94RM
Summary of Contents for IBT Technologies NMF94RM
- Page 1 Intel Q87 Express Chipset Based M/B for LGA 1150 Quad Core Ready Intel Core Processor NMF94RM Rev: 1.0 Release date: March 23, 2015 Trademark: * Specifications and Information contained in this documentation are furnished for information use only, and are...
-
Page 2: Table Of Contents
TABLE OF CONTENT ENVIRONMENTAL SAFETY INSTRUCTION ............... iii ENVIRONMENTAL PROTECTION ANNOUCEMENT............iii USER’S NOTICE ........................iv MANUAL REVISION INFORMATION ................... iv ITEM CHECKLIST ........................ iv CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD SPECIFICATION ....................1 LAYOUT DIAGRAM ....................2 CHAPTER 2 HARDWARE INSTALLATION JUMPER SETTING.................... -
Page 3: Environmental Safety Instruction
Environmental Safety Instruction Avoid the dusty, humidity and temperature extremes. Do not place the product in any area where it may become wet. 0 to 40 centigrade is the suitable temperature. (The figure comes from the request of the main chipset) ... -
Page 4: User's Notice
USER’S NOTICE COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER. -
Page 5: Chapter 1 Introduction Of The Motherboard
Chapter 1 Introduction of the Motherboard 1-1 Specification Spec Description Design Micro-ATX form factor; PCB size: 24.4 x24.4 cm ® Chipset Intel Q87 Express Chipset ® Supports Intel Gen. Core™ i7, Core™ i5, Core™ i3 series, ® CPU Socket Pentium processor in LAG1150 Package... -
Page 6: Layout Diagram
1-2 Layout Diagram Rear IO Diagram USB 2.0 Ports USB 3.0 Ports LAN2 RJ-45 LAN Port PS/2 Mouse Port VGA1 Port PS/2 Keyboard Port HDMI Port LAN1 COM1 Port RJ-45 LAN Port Motherboard Internal Diagram SMBUS Header 12V Power Connector Main Power Connector DDRIII DIMM Slot x 4 PS/2 Mouse Port... - Page 7 Motherboard Jumper Position JBAT AT_COPEN Jumper Jumper Name Description JBAT CMOS RAM Clear Function Setting 3-pin Block COM1 Port Pin9 Function Select 4-pin Block COM2 Header Pin9 Function Select 4-pin Block Mini-PCIE Slot (MPE) Power VCC3.3V/3.3VSB Select 3-pin Block ME_Feature Measure Function Select 2-pin Block For Factory Test 2-pin Block...
- Page 8 Connectors Connector Name ATXPWR ATX Power Connector ATX12V1 ATX 12V Power Connector SATA_PWR SATA Power Out Connector SATA1/2/3/4/5/6 SATAIII Connector x6 KBMS(Top) PS/2 Mouse Port Connector KBMS(Bottom) PS/2 Keyboard Port Connector HDMI HDMI Port Connector USB30 USB 3.0 Connector X2 USB20 USB 2.0 Connector X4 VGA1...
-
Page 9: Chapter 2 Hardware Installation
Chapter 2 Hardware Installation 2-1 Jumper Setting JBAT (3-pin): Clear CMOS Function Settings JBAT 1-2 Closed: Normal; 2-3 Closed: Clear CMOS. JP1 (4-pin): COM1 Port Pin9 Function Select JP1→COM1 Port 2-4 Closed: 3-4 Closed: 4-6 Closed: RI=RS232; RI= +5V; RI= +12V. JP4 (4-pin): COM2 Header Pin9 Function Select JP4→COM2 Port 2-4 Closed:... - Page 10 JP5 (3-pin): Mini-PCIE (MPE) Slot VCC 3.3V/3.3VSB Select JP5→Mini-PCIE (MPE) Slot 1-2 Closed ： MPE Slot VCC= 3.3V; 2-3 Closed ：MPE Slot VCC= 3.3VSB. JP3 (2-pin): ME Security Measure Function Select 1-2 Open:Enable Security Measures in the Flash Descriptor(Default) ; 1-2 Closed:Disable Security Measures in the Flash Descriptor(Override).
-
Page 11: Connectors And Headers
Pin 3 & 4 of AT_COPEN (4-pin): Case Open Message Display Function Select → AT_COPEN (Pin 3&4) Case Open Function Select Pin 1 3-4 Open: Normal; Pin 1 3-4 Close: Case Open Function Selected (One Touch). Pin 3-4 Close: When Case open function pin short to GND, the Case open function was detected. -
Page 12: Motherboard Internal Connectors
(6) COM1: Serial port Connector This serial port is for user to connect compatible mouse, modern or other peripherals. (7) LAN1/LAN2: RJ-45 LAN Port Connectors The connectors are standard RJ-45 connectors for Network. 2-2-2 Motherboard Internal Connectors (1) ATXPWR (24-pin block): Main Power Connector ATX Power Supply connector: This is a new defined 24-pins connector that usually comes with ATX case. - Page 13 Figure1：20-pin power plug Figure 2：24-pin power plug (2) ATX12V1 (4-pin block): 12V Power Connector This is a new defined connector that usually comes with ATX Power Supply that supports extra 12V voltage to maintain system power consumption. Without this connector might cause system unstable because the power supply can not provide sufficient current for system.
-
Page 14: Header Pin Definition
(4) SATA_PWR (4-pin block):: SATA Power Out Connector Pin1 Pin No. Definition +12V 2-2-3 Header Pin Definition (1) JW-FP1 (9-pin): Front Panel Header Pin 1 (2) SPK-LED (7-pin): PWR LED Header & Speaker Header Pin 1... - Page 15 (3) F_USB1/ F_USB2 (9-pin): USB 2.0 Port Header Pin 1 (4) TPM1 (19-pin): TPM 1.2 Header Pin 1 (5) COM2 (9-Pin): Serial Port Header Pin1...
- Page 16 (6) GPIO1 (10-pin): GPIO Header Pin 1 (7)LAN1_LED1/ LAN2_LED2 (2-pin): LANLED Status Indicator Header LED- Pin1 LED+ (8)VGA2 (15-pin): VGA Port Header DCC_CLK HSYNC VSYNC DCC_DATA VCC_VGA BLUE GREEN Pin 1 *Note: VGA2 header shares with VGA1 port, i.e., only one of them can work at a time at user’s choice.
- Page 17 (9) FP_USB30 (19-pin): USB 3.0 Port Header Pin 1 (10)SMBUS1 (4-pin): SM BUS Header Pin1 (11) CPUFAN1/SYSFAN1/SYSFAN2/SYSFAN3/SYSFAN4 (4-pin): FAN Headers Pin1...
-
Page 18: Chapter 3 Introducing Bios
Chapter 3 Introducing BIOS Notice! The BIOS options in this manual are for reference only. Different configurations may lead to difference in BIOS screen and BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard. Users are welcome to download the latest BIOS version form our official website. -
Page 19: Function Keys
Menu Bar General Help Items Current Setting Value Menu Items Function Keys Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here: ... -
Page 20: Menu Bars
3-5 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic configuration Advanced To change system advanced configuration Chipset To change chipset configuration Boot To change boot settings Security Password settings Save & Exit Save setting, loading and exit options. -
Page 21: Advanced Menu
3-7 Advanced Menu Trusted Computing Press [Enter] to enable or disable Security Device Support. Configuration Security Device Support Use this item to enable or disable BIOS support for security device. TCG EFI protocol and INT1A interface will not be available. The optional settings: [Disabled];... - Page 22 Use this item to turn on/off the Mid Level Cache (L2) streamer prefetcher. Adjacent Cache Line Prefetch The optional settings are: [Disabled]; [Enabled]. Use this item to turn on/off prefetching of adjacent cache lines. EIST The optional settings: [Disabled]; [Enabled]. Use this item to enable or disable Intel SpeedStep.
- Page 23 ME FW Image RE-Flash Use this item to enable or disable ME FW Image Re-Flash function. The optional settings: [Disabled]; [Enabled]. * In the case that user needs to update ME firmware, user should set ‘ME FW Image Re-Flash’ as [Enabled], save the settings and exit. The system will turn off and reboot after 4 seconds.
- Page 24 The optional settings are: [Enabled]; [Disabled]; [Auto]. [Enabled]: To enable legacy USB support. [Disabled]: to keep USB devices available only for EFI specification, [Auto]: To disable legacy support if no USB devices are connected. XHCI Legacy Support The optional settings are: [Disabled]; [Enabled]. XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
- Page 25 Serial Port Use this item to enable or disable serial port (COM). Change Settings Use this item to select an optimal setting for super IO device. ERP Support The optional settings: [Auto]; [Disabled]. This item should be set as [Disabled] if you wish to have all active wake-up functions.
-
Page 26: Chipset Menu
Temperature Use this item to set CPUFAN/SYSFAN1/ SYSFAN 2/ SYSFAN 3/ SYSFAN 4idle speed temperature. Fan will run at idle speed when below this temperature. CPUFAN / SYSFAN/ SYSFAN2 / SYSFAN3 / SYSFAN4 Idle-Speed Duty Use this item to set CPUFAN/SYSFAN1/ SYSFAN 2/ SYSFAN 3/ SYSFAN 4 idle speed duty. - Page 27 Use this item to enable or disable onboard Intel I217LM LAN controller. Wake on I217LM LAN The optional settings are: [Enabled]; [Disabled]. This item is affected by ERP function. Please disable ‘ERP Support’ before activating this function. Intel I211AT LAN Use this item to enable or disable onboard Intel I211AT LAN controller.
-
Page 28: Boot Menu
Primary Display Use this item to select which of IGFX/PEG/PCI graphics device should be primary display or select SG for switchable GFX. The optional settings are: [Auto]; [IGFX]; [PEG]; [PCIE]. Internal Graphics The optional settings are: [Auto]; [Disabled]; [Enabled]. Aperture Size The optional settings are: [128MB];... -
Page 29: Security Menu
Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. Bootup Numlock State Use this item to select keyboard numlock state. The optional settings are: [On]; [Off]. Quiet Boot The optional settings are: [Disabled]; [Enabled]. Boot Option Priorities ... -
Page 30: Save & Exit Menu
Security menu allow users to change administrator password and user password settings. 3-11 Save & Exit Menu Save Changes and Reset This item allows user to reset the system after saving the changes. Discard Changes and Reset This item allows user to reset the system without saving any changes. Save Changes This item allows user to save changes done so far to any of the setup options.
