I. Installation & Operation - EXP-LED-FX2R-2M
I. Operation
Momentary Mode:
Lightly press the top body switch for
momentary operation. Release the switch to
turn the light off.
Constant-On Mode:
Press the top body switch until it clicks and
then release for constant-on mode. Press
and release the top body switch again to turn
the light off.
Floodlight Mode:
Press the bottom body switch until it clicks
and then release for floodlight mode. Press
and release the bottom body switch again to
turn the light off.
Dual-Light Mode:
Dual-Light allows the user to turn on both the
flashlight and the floodlight, at the same time.
Press the top body switch until it clicks and
then release for constant-on mode flashlight
Mode. Next press and release the bottom
switch to activate the floodlight. Both the
flashlight and the floodlight are now running.
Press and release both the top and bottom
body switches to turn the lights off.
On/Off Button for
Flashlight
Charging
Station
Belt Clip with
Magnet
1
On/Off Button for
Floodlight
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Larson Electronics EXP-LED-FX2R-2M
Summary of Contents for Larson Electronics EXP-LED-FX2R-2M
- Page 1 I. Installation & Operation - EXP-LED-FX2R-2M I. Operation On/Off Button for Momentary Mode: Flashlight Lightly press the top body switch for momentary operation. Release the switch to turn the light off. Charging Station Constant-On Mode: Press the top body switch until it clicks and then release for constant-on mode.
- Page 2 II. Rechargeable Battery Replacement I. Battery Replacement 1. Loosen the locking screw located on the 6. Using only the approved replacement side of the lens cap. CAUTION: Do NOT rechargeable battery pack, slide the new attempt to completely remove the locking battery pack into the handle of the light using screw.
- Page 3 II. Warnings and Safety Ratings I. Warnings II. Ratings Use only the approved non-rechargeable Listed for United States, Canada, Europe batteries listed below. Class I, Division 1 & 2, Groups A,B,C,D Class II, Division 1 & 2, Groups E,F,G Do NOT attempt to use rechargeable AA Class I, Zone 0, AEx ia IIC T3 Ga batteries with this light.
