Larson Electronics AEX-20-LED-SA Instruction Manual

15W, 2000 Lumen Spotlight - 2W, 300 Lumen Floodlight

Warning:

Never place light face down when light is on. Doing so could burn/ignite surfaces such as seats, carpeting, etc. and
cause major property damage. Always turn light off when not in use.
Avoid direct eye exposure the light source when light is on. DO NOT shine light into the face of someone else.
DO NOT touch lens of light when on or recently on. The lens will be hot after long periods.
DO NOT allow children to handle or operate this light.
DO NOT use this product for anything other than its intended use.
DO NOT operate in close proximity of combustible or flammable materials.
DO NOT attempt to operate this light if cord, plug, battery, lens or any part of the light is damaged or corroded.
The AEX-20-LED-SA from Larson Electronics is a LED Light that is a powerful, portable flashlight that is designed for
illumination in wet weather and dusty conditions. The battery-powered unit features a primary 15-watt spotlight (2000
lumens) and a secondary 2-watt floodlight located on the side (300 lumens) for a total light output of 2,300 lumens with
a color temperature rating of 5,000 K. This heavy-duty luminary is dimmable and offers 5 hours of continuous use per
charge. During emergency situations, the LED light doubles as an SOS strobe light via a built-in strobing feature. The
AEX-20-LED-SA is a complete kit that includes the flashlight, hard carrying case, shoulder strap, wall charger, and
vehicle charger.

Power and Battery

This light is powered by a 2,600 mA battery that is rechargeable via a docking
station. The power cell is removable, but not required. Charging time to full
capacity is 3.75 hours, while runtime in a fully charged state is 5 hours. The
explosion proof LED flashlight features a lengthy operational lifespan of 50,000
+ hours. This unit's wall charger is offered in the following voltage options: 120
V AC or 240 V AC, specified when ordering. A 12 V - 24 V vehicle charger is
also included. The light is shipped with minimum charge on the lithium battery.
It is necessary to condition and charge the battery before using your light for
the first time.

Exploded View:

O-ring
Rubber end
cap cover
Lens cap
NOTE: When starting for the first time (cold start),
it is recommended to leave it on for a minimum of
one minute before turning it off. This allows the
lamp time to achieve a temperature hot enough to
vaporize the additives and prevent deposits from
forming on the inner arc chamber walls. When
warming up it is normal for the lamp to "flicker",
this is the result of the metal salts in the arc
chamber vaporizing. You will also see a slight
shade of red and blue. As the light comes to
temperature the flickering will subside, the arc will
stabilize and the light output will increase.
Larson Electronics, LLC
17W Rechargeable LED Flashlight
Instruction Manual
Light head
Spacer ring
Lamp module
Lens
Phone: (800) 369-6671
On/off swith
Battery pack
housing
Ballast housing
293.2
Fax: (903) 498-3364
AEX-20-LED-SA
Rubber end
cap cover
96.0
www.larsonelectronics.com
Charger jack
