Summary of Contents for Atlas Cyclops
-
Page 2: Check List
Check List OPERATING INSTRUCTIONS: Preparation For Installation, Product Identifi cation Check Charging The Batteries Check Checking And Adjusting The Lift Check Mounting Head’s Brackets Check Mounting Clamps And Quick-Locking Arms Check Installation Of Accessories On The Control Unit And First Start Check Registration Of Heads On The Lift Adjusting The Angle Of The Measurement Heads... -
Page 3: Quick Start Steps
Quick Start Steps Unpack The Wheel Aligner Box Targets Control Measuring Unit heads Clamps Targets Monitor Printer Mechanical turn tables Quick Start Steps Cyclops... - Page 4 (ramps at different heights) but to do this, it is has to start from a known condition: LIFT LEVELED AT THE GROUND POSITION ! ! Quick Start Steps Cyclops...
- Page 5 Drive-in Direction Measure for the Left side ramp Drive-in Direction Using the heads support as a template, mark the spot where drilling, drill with a drill bit for steel diameter of 6.7 mm and thread M8. Quick Start Steps Cyclops...
- Page 6 Locking arms properly mounted with knobs at “6 o’clock” Knobs at “6 o’clock”- OK Connect the quick locking device on the clamp Attach the Insert the clips to lock the pin. claws Assemble the springs. Attach the claws. Quick Start Steps Cyclops...
- Page 7 Remove the printer from the box and connect it to the power outlet and the USB cable from the computer. Remove the SMART CARD from the plastic bag and place it correctly in the reader Quick Start Steps Cyclops...
- Page 8 Blue color which tells us that the heads are connected with the Computer. Now mount the heads of their respective supports. Make sure that the arrow stuck on the cover is facing the driving direction of the vehicle. Quick Start Steps Cyclops...
- Page 9 F4 to access the next page. By pressing the F2 or F3 move the cursor to select “Measure Head: onboard sensor”. Confi rm by pressing F4 to access the next page. The measuring heads must be switched on. Quick Start Steps Cyclops...
- Page 10 This adjustment is used to compensate different heights between the left and right ramps of the lift. Installations on the fl oor (in the pit) and lifts who have ramps at the same height do NOT require this adjustment. To perform this procedure: Read the service manual. Quick Start Steps Cyclops...
- Page 11 Go in front of the monitor and from the logo page displayed on the right, proceed as follows: Press the “F2” key (blue) Press “F2” or “F3” key (blue or yellow) to move the cursor to “System Confi guration”. Press “F4” to continue. Quick Start Steps Cyclops...
- Page 12 Target if wrong or not present. When you press the “F1” key to exit this page, the program will automatically copy the fi les from USB to PC, if not already done. Quick Start Steps Cyclops...
- Page 13 Target in right correct position, rotate position – lock slowly and lock With the pin slightly braked, turn the target THE TARGET WHEN REACHED THE until you fi nd the correct position. RIGHT POSITION MUST BE LOCKED Quick Start Steps Cyclops...
- Page 14 • How you want to display the vehicles database • You have to write the heading of the client, the address, the phone, to be saved and printed in the report. Please consult your service manual and user manual for this information. Quick Start Steps Cyclops...
