Or-Fab 83228 Installation Instructions

INSTALLATION INSTRUCTIONS

WARNINGS/CAUTIONS

Before you install this kit, read and understand
all instructions, warnings, cautions, and notes in
this instruction sheet and in the vehicle owner's
manual.
Proper installation of this kit requires knowledge
of the factory recommended procedures for removal
and installation of original equipment components.
We recommend that the factory shop manual and
any special tools needed to service your vehicle
be on hand during the installation. Installation of
this kit without proper knowledge of the factory
recommended procedures may affect the perfor-
mance of these components and the safety of the
vehicle. We strongly recommend that a certified
mechanic familiar with the installation of similar
components install this kit.
Many states and municipalities have laws
restricting bumper heights and "type". Consult
state and local laws to determine if the changes
you intend to make to the vehicle comply with
the law.
Always wear eye protection when operating
power tools.
If parts are missing from kit, please be prepared
to provide the following information:
1. Name of purchase location
2. Bar Code on side of box
3. Date above bar code
4. Date inside box cover
5. Inspector # from inside box cover
421 MAIN STREET, RIVERSIDE CA, 92501
JEEP Wrangler JK Full/Mid Width Front
Bumper
2007-2017
Item
Centered Fairlead for Regular
Winches Kit
Non-Hoop
Offset Fairlead for Larger Winches
–
Non-Hoop (Warn PowerPlant Included)
2012+ Models May Require: 87046 Relocation Kit

BEFORE STARTING INSTALLATION

NOTE
Kit parts are prefaced by the word kit
1. Carefully read all warnings and instructions
completely before beginning.
2. Instructions are written for installation of
both centered (83228/83230/83238/83234)
and offset (83227/83229/83237/83233)
bumper. Pay close attention for minor differ-
ences during install.
3. Verify all parts have been received in this kit
by checking the parts list at the end of this
document..
4. Only install this kit on the vehicle for
which it is specified. If anytime during
the installation you encounter something
different from what is outlined in the
instructions, call technical support at the
number below.
4. Park vehicle on a clean, dry, flat, level sur-
face and block tires so vehicle cannot roll in
either direction.
Engine Compartment
1. Disconnect both battery cables. Disconnect
negative cable first, then positive cable.
