1 INTRODUCTION
TagTemp-S is an electronic temperature data logger. The
temperature measured by the sensor is recorded in device internal
memory. This data is transferred through a smartphone equipped
with an embedded NFC interface or by an NFC interface connected
to a computer through an USB port (both not included).
LogChart-NFC application for ANDROID™ and the NXperience for
Windows® are the tools used to configure the operating mode,
transfer and display data. The acquisition start and end parameters,
logging interval, setpoint alarms and other parameters can be easily
defined using these applications.
The operating manual and NXperience can be downloaded from
the manufacturer's website. The ANDROID™ LogChart-NFC app
can be downloaded from Google Play Store.
2

MECHANICAL INSTALLATION

TagTemp-S can be installed using a double-sided adhesive tape on
the back of the device, taking care not to stick it over the
identification tag. Another way is to use the blister hole to attach the
transmitter.
NOVUS AUTOMATION
3

TECHNICAL FEATURES

Operating
-30 °C to 60 °C.
Temperature
Storage
From -30 °C to 65 °C.
Temperature
Measuring Range
Temperature: -30.0 °C to +60.0 °C.
±1 °C max. over the full measuring range.
Note:
Accuracy of
measurement error in the "Offset"
Measurement
parameter
software.
Measurement
Temperature: 0.1 °C / 0.1 °F.
Resolution
Memory Capacity 4020 registers.
1 minute min.
Interval between
Measurements
4 hours max. (240 minutes).
3.0 V lithium battery (CR2032), built-in,
Power Supply
non-replaceable.
Battery Life Above 2 years at a 5-minute acquisition
(estimated) interval.
Dimensions 37 x 57 x 8 mm.
RF Interface ISO 15693 (NFC-V) compatible.
Data Transfer Time
Approx. 20 seconds (depends on the
between Register
smartphone processing speed).
and Smartphone
ANDROID™ version: 4.0 or above.
LogChart-NFC
Application
Languages: Portuguese or English.
USB
NFC interface for
compatible
the computer
Windows®.
Case Polyvinyl Chloride (PVC).
All electronics are protected by the
Degree of protection
housing. IP65 compatible.
Certification
CE
TagTemp-S
The user can correct the
using the configuration
to NFC interface (optional),
NXperience
with for
