- Page 1 INSTALLATION & OWNER’S MANUAL Nexus Series Inverter Mini Chillers KEM-05 DVN1 KEM-12 DVN KEM-16 DTN KEM-07 DVN1 KEM-12 DTN KEM-10 DVN KEM-14 DTN Original instructions Thank you very much for purchasing our product.
-
Page 2: Table Of Contents
1. INTRODUCTION CONTENTS PAGE 1.1 General information ■ These units are used for both heating and cooling applications. 1. INTRODUCTION................ 1 They can be combined with fan coil units, floor heating 2. ACCESSORIES................. 1 applications (connect the mixed station), low temperature high efficiency radiators (field supply). -
Page 3: Safety Considerations
3. SAFETY CONSIDERATIONS manual using a separate circuit. Insufficient capacity of the power supply circuit or improper electrical construction may lead to electric shocks or fire. The precautions listed here are divided into the following types. They are quite important, so be sure to follow them carefully. ■... -
Page 4: Overview Of The Unit
c) Where there is machinery which emits electromagnetic waves. Electromagnetic waves can disturb the control system and cause equipment malfunction. d) Where flammable gases may leak, where carbon fiber or ignitable dust is suspended in the air or where volatile flammables such as paint thinner or gasoline are handled. - Page 5 Refrigerant cycle 25 HP LP 26 Electrical control box introduces 4.4.1 5/7kW (1-phase) The electrical control box is located inside the unit at the top of the technical compartment where the various components of the refrigerant circuit are also to be found. To access the electrical panel, remove the front panel of the unit by undoing the screws.
- Page 6 1. ELECTRICAL PANEL LAYOUT (The picture below shows the position of the diagram, please participate in the concrete photos) ⑤ ⑥ ④ ③ ② ① ⑦ ① Main control board ④ FC inductance ⑦ Customer connection terminal ② DC filter board ⑤...
- Page 7 4. Main control board (The picture is for reference only) 1.Power L 17.Electronic expansion valve 2.Power N 18.DC fan power supply port 3.Preliminary charging relay (rectifier bridge input port 1) 19.DC fan port 4.Input rectifier bridge line (rectifier bridge input port 2) 20.Remote control port 5.5A fuse 21.Force cooling switch...
- Page 8 2. Main control board (The picture is for reference only) Transformer output port Rectifier bridge input port L 2.Tin/Tb1/Tout/Tb2 temperature sensor port 8A fuse tube Note: Tin: water inlet temp. Tout: water outlet temp. Solenoid valve port (Reserved) Tb1: Temp. 1 of plate heat exchanger Exhaust valve electric heater port Tb2: Temp.2 of plate heat exchanger Plate heat exchanger electric heater port...
- Page 9 3. PFC&IPM module board (The picture is for reference only) 1. +18V output port Input Port P for IPM Power supply port W of the compressor Power supply port V of the compressor Power supply port W of the compressor PFC output N PFC output P PFC inductance port L_1...
- Page 10 2. Main control board (The picture is for reference only) 1. Input port for switching power supply 14. Remote control port 2. Debugging port 15. Electronic expansion valve port 3. Connection port for operation and display panel 16. AC 220V power supply port 4.
- Page 11 3. IPM module board (The picture is for reference only) 1. +15V output port 5. Compressor connection port V 2. communication port to main 6. Compressor connection port U control board 7. IPM input P 3. IPM input port N 8.
-
Page 12: Unit Installation
UNIT INSTALLATION 5.1 Before installation Before installation Be sure to confirm the model name and the serial number of the unit. Handling Due to relatively large dimensions and heavy weight, the unit should only be handled using lifting tools with slings. The slings can be fitted into foreseen sleeves at the base frame that are made specifically for this purpose. - Page 13 ■ To prevent exposure to wind, install the unit with its suction side facing the wall. ■ Never install the unit at a site where the suction side may be exposed directly to wind. ■ To prevent exposure to wind, install a baffle plate on the air discharge side of the unit.
- Page 14 5.3.1 Moving and installation 5.3.2 Water Outlet Since the gravity center of the unit is not at its physical The condensed water outlets on the chassis for selection center, so please be careful when lifting it with a sling. display as the follow figure: 5/7kW Never hold the inlet of the outdoor unit to prevent it from deforming.
- Page 15 5.4 TYPICAL APPLICATION EXAMPLES The application examples given below are for illustration purposes only. 5.4.1 Application 1 Space cooling and heating application with a standard controller (or optional wired controller) connected to the unit. FCU1 FCU2 FCUn outdoor unit balance tank (field supply) Y-shape filter 9.1 air purge valve shut-off valve (field supply)
- Page 16 5.4.2 Application 2 Space heating only application with a standard controller (or optional wired controller) connected to the unit. Heating is provided through floor heating loops. 22 8 FHL2 ..FHL1 FHLn 1 outdoor unit balance tank (field supply) 2 Y-shape filter 9.1 air purge valve 3 shut-off valve (field supply) 9.2 drain valve...
- Page 17 5.4.3 Application 3 Space cooling and heating application with a standard controller (or optional wired controller) connected to the unit. Heating is provided through floor heating loops and fan coil units. Cooling is provided through the fan coil units only. FCU1 FCU2 FCUn...
- Page 18 5.4.4 Application 4 Space cooling and heating application with a standard controller (or optional wired controller) connected to the unit. Heating is provided through floor heating loops. Cooling is provided through the fan coil units only. The 3-way valve is used to change the direction of water flow when the operation mode changed.
- Page 19 5.4.5 Application 5 Space heating with an auxiliary boiler (alternating operation). Space heating application by either the unit or by an auxiliary boiler connected in the system. ■ The unit controlled contact (also called "permission signal for the auxiliary boiler") is required on-site, and it is recommended that the signal be determined by the outdoor temperature (thermistor located at the outdoor unit).
- Page 20 Application B If application B is selected, the control cable connect to the boiler should also connect to the 3-way valve (16) FCU1 FCU2 FCUn outdoor unit balance tank (field supply) Y-shape filter 9.1 air purge valve shut-off valve (field supply) 9.2 drain valve wired controller (optional) expansion vessel (field supply)
- Page 21 Before continuing installation of the unit, check the following: 5.5 Water pipe installation ■ The maximum water pressure can not exceed 3 bar. ■ The maximum water temperature is 60°C according to safety NOTE device setting. ■ Always use materials that are compatible with the water used in the ■...
- Page 22 2. Check that the total water volume in the entire water circuit ■ Because brass is a soft material, use is lower than this value. appropriate tools for connecting the If this is not the case, the expansion vessel inside the unit is too small water circuit.
- Page 23 5.5.7 Fouling factors WARNING The performance data given refer to conditions with clean evaporator plates (fouling factor=1). For different fouling factors, ETHYLENE GLYCOL AND PROPYLENE GLYCOL ARE TOXIC multiply the figures in the performance tables by the coefficient given in the following table. a.The concentrations mentioned in the table above will not prevent the medium freezing, but will prevent the hydraulics from Fouling factors...
- Page 24 5.6.3 Electrical connection ■ Never squeeze bundled cables and make sure they do not come in contact with the piping and sharp edges. Make sure no external pressure is applied to the terminal connections. The unitary mini chillers leave the factory already wired, and require ■...
- Page 25 Electrical Power Connection Remote cooling/heating 1-phase 3-phase N GND N GND SWITCH 2 If switch2 is closed, the unit will shift to heating mode forcibly; If switch2 breaks the unit will shift to cooling mode forcibly. Residual Current Residual Current Circuit-breaker Circuit-breaker NOTE...
-
Page 26: Start-Up And Configuration
4. The Specification of Power TYPE 10kW/12kW 12kW/14kW/16kW Phase 1-Phase 1-Phase 1-Phase 3-Phase Power Frequency and Volt 220-240V~, 50Hz 220-240V~, 50Hz 220-240V~, 50Hz 380-415V~, 50Hz 25/20 Circuit Breaker / /Fuse (A) 30/25 30/25 40/35 3x4.0 3x4.0 3x6.0 5x4.0 Power Wiring (mm Ground Wiring (mm IMPORTANT The power cord type designation is H07RN-F. - Page 27 6.2.1 Hydraulic operational area constant speed Ⅰ,Ⅱ,Ⅲ Constant speed ⅠⅡⅢ Constant speed ⅠⅡⅢ p/kPa 4300 / in RS 15/6 RKC RS25/7.5 RKC 1~230V-Rp1 1~230V-Rp1 1/4 4640 /min p/kPa 3400 / in 2390 / in 2970 /min /mi n 1270 /min Q/l/s Q/l/s 16 Q/lgpm...
-
Page 28: The Host Unit Controller Elucidation
6.2.4 Failure diagnosis when first installation 6.2.3 Static Pressure Drop Unit 5/7kW ■ If nothing is displayed on the user interface, it is necessary to check for any of the following abnormalities before diagnosing 70.0 possible error codes. 60.0 ■ Disconnection or wiring error (between power supply and unit and between unit and user interface). - Page 29 7.2 Activating and deactivating the unit 7.2.1 Icon Description The front panel of the device functions as the user interface and is used to perform all operations relating to the device. Icon Description ① Outside heat source running icon(Reserved) Cooling mode icon ②...
- Page 30 Icon Description Frequency unit icon It will be constantly light when the control panel displays frequency of the compressor. ON/OFF and OK button 1.Press “ ” to confirm the former operation when finishing the setting work. 2.Long press “ ” for 3S will recovers to factory default mode. Mode choice function/Function choice/Back function button 1.Mode choice function.
- Page 31 ● Long press “ ” for 3s to return to the previous interface to reset the parameter during setting clock timing. 2）Timing off setting ①Long press “ ” for 3s in the main interface to enter function interface. Press “ ”...
- Page 32 7.2.3 Functions of combination key 3. Auto-lock(unlock) function 1. Force cooling If don’t operate the controller in 60s, the keyboard will lock Press “ ” and “ ” simultaneously for 3s in the main automatically. Press “ ”and “ ” simultaneously for 3s interface to enter into force cooling mode.
-
Page 33: Trouble Shooting
5. Fan speed control 7.3 Operating characteristics For correct operation of the unit with different ambient 1. Set temperature in cooling temperatures, the microprocessor controls the fan speed based Range:10~20℃ （default：12℃） on the ambient temperature and the condensing or evaporation If the set temperature is between 10~13℃, the compressor start and temperature as well as compressor frequency, thus enabling heat shut down according to the difference between the inlet temperature... -
Page 34: Important Information For The Used Refrigerant
9. IMPORTANT INFORMATION FOR THE 8.1 General guidelines USED REFRIGERANT Before starting the troubleshooting procedure, carry out a thorough visual inspection of the unit and look for obvious defects such as This product has the fluorinated gas, it is forbidden to release to air. loose connections or defective wiring. -
Page 35: Main Parameters
10. MAIN PARAMETERS Model 220-240, 1, 50 220-240, 1, 50 220-240, 1, 50 220-240, 1, 50 380-415, 3, 50 380-415, 3, 50 380-415, 3, 50 V-Ph-Hz Power supply 5.0(1.9~5.8) 7.0(2.1~7.8) 10.0(2.9~10.5) 11.2(3.1~12.0) 11.2(3.1~12.0) 12.5(3.3~14.0) 14.5(3.5~15.5) Capacity rated Input 1550 2250 2950 3500 3380... - Page 36 Product fiche 1 Outdoor KEM-05 DVN1 KEM-07 DVN1 KEM-10 DVN KEM-12 DVN Heat pump space heater Indoor Indoor unit sound power (*) [dB(A)] Outdoor unit sound power (*) 63.0 66.0 68.0 [dB(A)] 68.0 Space heating Energy efficiency class 35°C (Low temp. app.) Average climate (Design temperature = –10°C)
- Page 37 Product fiche 2 Outdoor KEM-12 DTN KEM-14 DTN KEM-16 DTN Heat pump space heater Indoor Indoor unit sound power (*) [dB(A)] Outdoor unit sound power (*) [dB(A)] 68.0 70.0 72.0 Space heating Energy efficiency class 35°C (Low temp. app.) Average climate (Design temperature = –10°C) Prated (declared heating capacity) @ –10°C [kW] 12.3...
- Page 38 Technical parameters Model(s): KEM-05 DVN1 Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 39 Technical parameters Model(s): KEM-07 DVN1 Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 40 Technical parameters Model(s): KEM-10 DVN Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 41 Technical parameters Model(s): KEM-12 DVN Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 42 Technical parameters Model(s): KEM-12 DTN Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 43 Technical parameters Model(s): KEM-14 DTN Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 44 Technical parameters Model(s): KEM-16 DTN Air-to-water heat pump: Water-to-water heat pump: Brine-to-water heat pump: Low-temperature heat pump: Equipped with a supplementary heater: Heat pump combination heater: Parameters shall be declared for medium-temperature application, except for low-temperature heat pumps. For low-temperature heat pumps, parameters shall be declared for low-temperature application.
- Page 45 MD14IU-023LW...
