Comeup CWL-301L Instructions

Compact winch
Hide thumbs Also See for CWL-301L:
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual

Introduction

Feature

Lifting capacity: 300 kg wire rope top layer
Lifting height:
Lifting speed:
Motor output:
Brake:
Control:

Unpacking

．Winch assembly
．Wire rope 6 mm x 60 m
．Weight hook CHW-0031
．Pendant switch
Read this manual carefully
You should carefully read and understand this manual before operating it.
Careless winch operation may result in personal injury hazards or property
damage.
Information requesting or parts ordering
Please specify the followings information:
．Winch PN
．Serial number
．Part description
．Replacement part number
．Quantity for each part
58 m
16 – 25 m/min
2.3kw x 11A at 220-240V
Electromagnetic and mechanical ratchets
Pendant switch powers the winch
PB-317
w/cord 2.0 mm
Compact Winch
CWL-301L
Model:
PN : 374696 220V 374700 230V
374545 230V
2
x 6C x 10m
374798 240V
1pc
1pc
1pc
1pc
