Stonewood Manor Upholstered Beds
RGB = Rustic Glazed Brown finish
Assembly Instructions
Model #
5618RGB
Stonewood Cal-King
Manor Upholstered
Storage Bed
Manor Upholstered Bed
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
5643RGB
Stonewood Cal-King
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Remove items before you move this unit.
• Do not overload the drawers.
• This assembly requires two people.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
06/16
Advertisement
Related Manuals for Whittier Wood 5618RGB
Summary of Contents for Whittier Wood 5618RGB
- Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
- Page 2 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Parts List Please note this Assembly Instruction is for Stonewood Cal-King Manor Upholstered Storage Bed (#5618), and Stonewood Cal-King Manor Upholstered Rail Bed (#5643). The Parts Lists for each component follow.
- Page 3 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Parts List 5668UWT Stonewood Cal-King Manor Insert – Woven Taupe (x1) Part Description Quantity Upholstered Headboard Insert Back Support Assembly (attached) #8 x 1-1/8" Lo-Profile Screw (inserted) 5618RGB_5643RGB Page 3 —...
- Page 4 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Parts List 1735RGBa Pedestal Kit (x2) Part Description Quantity Pedestal Drawer Box (assembled) Drawer Face (attached) Trestle with T-Nuts (36-1/4") Center Deckboard Notched Deckboard (attached) Assembled Foot (attached) Drawer Slides (pre-installed sets) #6 x 3/4"...
- Page 5 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Parts List 1735RGBa Pedestal Kit (x2)_Cont. Part Description Quantity Right Bed Bracket (attached) Foot Bracket (attached) Adjustable Glide (installed) 1754RGBa Cal-King Rail Kit (x1) Part Description Quantity #8 x 1-1/4"...
- Page 6 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Tools Required: Phillips screwdriver, Slotted screwdriver, 1/2" & 7/16" open end or box end wrench and Tape measure Notes: Steps 1 through 10 are for the Stonewood Cal-King Manor Upholstered Storage Bed (#5618).
- Page 7 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Place the Headboard Assembly (A) face down on a clean, protected surface. Remove two pieces of foam blocks from the packaging and place them under the legs of the Headboard Assembly (A) so that the Upholstered Headboard Insert (ZR) can be set into place within the framework.
- Page 8 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Place both Pedestals (Da) approximately 74" apart as shown in Figure 3. 74" Fig. 3 To attach the Footboard (B) to the Pedestal (Da), align the Brackets and slide the Pedestal down on to the Footboard (B).
- Page 9 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Repeat step four for the other side. See Figures 5 and 5a. Fig. 5 Fig. 5a Align the Brackets on both sides and slide the Pedestal/Footboard assembly down on to the Headboard (A).
- Page 10 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Open the drawers. Face the Footboard and stand in between the first and second braces. Place a Trestle with T-Nuts (G) on the outside surfaces of the first upper left and right braces so that the T-Nuts (V) sit near the top.
- Page 11 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Face the Headboard and stand in between the third and fourth braces. Place a Trestle with T-Nuts (G) on the outside surfaces of the third upper left and right braces so that the T-Nuts (V) sit near the top.
- Page 12 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. Place your bed in its final position. Using a 1/2" wrench or Slotted screwdriver adjust the Adjustable Glides (ZE) on the bottoms of the Assembled Feet (J) so that the top edge of the trestles are 17"...
- Page 13 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. 11. Remove the diagonal braces from the back of the Headboard (A). See Figure 11. Diagonal braces Fig. 11 Continued on Page 14 5618RGB_5643RGB Page 13 —...
- Page 14 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. 12. Place the Headboard Assembly (A) face down on a clean, protected surface. Remove two pieces of foam blocks from the packaging and place them under the legs of the Headboard Assembly (A) so that the Upholstered Headboard Insert (ZR) can be set into place within the framework.
- Page 15 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. 13. To attach the Footboard (B) to the Side Rail (ZO), align the Brackets and slide the Side Rail (ZO) down on to the Footboard (B). See Figures 13 and 13a.
- Page 16 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. 15. Align the Brackets on both sides and slide the Side Rail/Footboard assembly down on to the Headboard (A). See Figure 15.
- Page 17 5618RGB Stonewood Cal-King Manor Upholstered Storage Bed; 5643RGB Stonewood Cal-King Manor Upholstered Bed Assembly Instructions This assembly requires two people. 17. Move the bed assembly to its final position. Position the Slats (ZI) on the bottom edges of the rails. Attach with #8 x 1-1/4" Black Screws (O). See Figure 17.
