Model #
1501GSPb 1501CAFb
Pacific Beveled Mirror
GSP = Glazed Spice finish
CAF = Caffè finish
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
•
For normal household use only. Not recommended for commercial use.
•
Handle the mirror with care. Glass is fragile.
•
Tighten or repair as needed
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
.
WARNING
03/17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood 1501GSPb
Summary of Contents for Whittier Wood 1501GSPb
- Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
- Page 2 1501GSPb 1501CAFb Pacific Beveled Mirror Parts List Please identify the parts and check that quantities received match those on this list. If you need to replace a part, refer to the following letter and part name. Part Description Quantity Mirror Assembly...
- Page 3 1501GACb 1501CAFb Beveled Mirror Assembly Instructions Tools Required: Phillips Screwdriver, Tape Measure, Pencil You have the option of attaching your Mirror to the wall or to selected Pacific Dressers. To attach the Mirror to a wall, follow steps 1-3. To attach the Mirror to the Dresser, follow steps 4-7.
- Page 4 1501GACb 1501CAFb Beveled Mirror Assembly Instructions 3. NOTE: The Mirror Wall Bracket (I) angles out at the top. When you hang your Beveled Mirror, the Mirror Frame Bracket (D) fits over the angled part of the Mirror Wall Bracket (I). See Figure 3.
- Page 5 1501GACb 1501CAFb Beveled Mirror Assembly Instructions 4. To attach the Mirror to a Pacific Dresser, remove the Mirror Frame Bracket (D) that is attached to the Mirror Frame (Cb). Keep this bracket along with the Mirror Wall Bracket (I) and the two #8x1-3/4"...
- Page 6 1501GACb 1501CAFb Beveled Mirror Assembly Instructions 6. Peel off the backings on the Velvet Pads (N) and apply them to the bottom of the Mirror Assembly (Ab). See Figure 6. Fig. 6 7. Place the Mirror on top of the Dresser and attach it to the Mirror Supports (K) with four #7 x 1-1/2"...
