- Page 1 Installation and Maintenance Manual MRPW-03 Performa Winch 46.2 PTP ™...
-
Page 2: Table Of Contents
Maximum working load Outline Installation Installation procedure Maintenance Washing Maintenance table Disassembly procedure Exploded view with maintenance products Assembly Harken limited worldwide warranty ® Ordering spare parts Exploded view Parts list 46.2 PTP Installation and Maintenance Manual Performa Winch ™... -
Page 3: Introduction
In case of doubt the Harken ® Tech Service is at your disposal at techservice@harken.it This Manual is available only in English. If you do not fully understand the English language, do not carry out the operations described in this Manual. -
Page 4: Installation
It is the installer's responsibility to choose the correct screws ® taking account of the loads they will have to bear. Harken assumes no responsibility for incorrect installation of its winches or for an incorrect choice of mounting screws. - Page 5 Procedure To install the winch you must remove the drum and use Socket Head (SH) bolts. Tools needed One medium fl at-bladed screwdriver To identify the various parts, refer to the exploded view at the end of this Manual. Torque to apply when assembling 2.
-
Page 6: Installation Procedure
B. Remove the winch and drill the five 8.2 mm diameter holes. ® C. Bolt the base of the winch to the deck using five M8 bolts (not supplied by Harken ), correctly chosen for the thickness and type of the boat deck. Consult the yard that built the boat in case of doubt. -
Page 7: Maintenance
Installation and maintenance of winches must be carried out exclusively by specialized personnel. In the case of doubt contact Harken ® Tech Service at techservice@harken.it 46.2 PTP... -
Page 8: Disassembly Procedure
Disassembly procedure Tools needed One medium fl at-bladed screwdriver A number fi ve hex key Rags To identify the various parts refer to the exploded view at the end of this Manual. Torque to be applied in assembly phase Carry out procedure as shown in the paragraph on winch installation and then do the following: 4. - Page 9 8. Remove the gear n°14 9. Remove the washer n°12 10. Remove the gearing n°9 and remove the pawls n°7 . To facilitate the operation press the spring against the pawl with a blade. 11. Slide off gear n°2 12. Remove the pinion n°10. 46.2 PTP Installation and Maintenance Manual Performa...
- Page 10 13. Slide off gear n°5 14. Remove the washer n°4. Inspect balls inside the drum and carefully check the correct position; if it is necessary to put back any balls, push balls in the race (as shown below): Once the winch is completely disassembled, clean the parts: use a basin of diesel oil to soak metal components and rinse plastic parts in fresh water.
-
Page 11: Exploded View With Maintenance Products
Exploded view with maintenance products Anti-seize Harken ® Grease Harken ® Pawl Oil Apply Harken grease on assy socket screw ® 46.2 PTP Installation and Maintenance Manual Performa Winch ™... -
Page 12: Assembly
Once in position, check that the pawls can be easily opened and closed with a fi nger. ® In case of doubt concerning the assembly procedure contact Harken Tech Service: techservice@harken.it ® Harken limited worldwide warranty Refer to the Harken ®... - Page 13 Manufacturer Harken Italy S.p.A. ® Tech Service Via Marco Biagi, 14 Email: techservice@harken.it 22070 Limido Comasco (CO) Italy Tel: (+39) 031.3523511 Customer Service Fax: (+39) 031.3520031 Tel: (+39) 031.3523511 Email: info@harken.it Email: info@harken.it Web: www.harken.com Headquarters Harken , Inc. ®...
-
Page 14: Exploded View
Exploded view 1/2 Radial Winch 46.2 PTP 46.2 PTP Installation and Maintenance Manual Performa Winch ™... - Page 15 Exploded view 2/2 Radial Winch 46.2 PTP 46.2 PTP Installation and Maintenance Manual Performa Winch ™...
-
Page 16: Parts List
Assy Housing Winch 46 HHousing Winch 46 Heli-coil M6x9 S414900080 Bushing Ø12xØ14x8 S413330085 Bushing Ø12xØ14x11 S4133200B3 Bushing for support M0606303 Screw M8x25 UNI 5931 *Available with service kit; see website www.harken.com **Winch product sticker 46.2 PTP Installation and Maintenance Manual Performa Winch ™...
