Secondary Remote Access Unit

The Secondary Remote Access Unit (SRAU) design allows for easier Band 1 and
Band 2 Mix-and-Matching per country and/or market needs. SRAU components
are as shown in the following figure.
BTS 1 BTS 1 BTS 1
BTS 2 BTS 2 BTS 2
BTS 3 BTS 3 BTS 3
Band 1 and 2 Boards
RAU pairing examples:
850/1900
700/700 MIMO
800/900 SMR
700 SISO/AWS
800/AWS
FlexWave Prism Remote Unit Installation Guide
ADCP-77-072 • Issue 2 • 11/2009
Connects to
Main RAU
(MRAU)
