BobsCNC E4 Assembly Manual

Simple cost effective designs
Hide thumbs Also See for E4:
Table of Contents

Advertisement

Quick Links

E 4
Assembly Manual
Version 1.00
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E4 and is the answer not in the manual?

Questions and answers

william
July 5, 2025

where can i purchase a E4 controller from bobs cnc?

0
Seamark Marine Inc.
April 13, 2025

I can't get back to the dialogue page for the credit card number.

0

Related Manuals for BobsCNC E4

Summary of Contents for BobsCNC E4

  • Page 1 Assembly Manual Version 1.00 Page 1...

  • Page 2: Table Of Contents

    Safety First Getting Started ······························································································· 5 Required Tools Good Ideas For More Information E4 Hardware Parts Guide ··············································································· 6 Z Spindle Mount Assembly Instructions ························································· 7-17 Wood Components (included with the kit) Required Hardware (included with the kit) Illustrated Steps Y Carriage Assembly Instructions ···································································...

  • Page 3: Table Of Contents

    Installing the Belts ·························································································· 73-77 Wood Components (included with the kit) Required Hardware (included with the kit) Illustrated Steps Electronic Installation····················································································· 78-86 Tips to Keep Your Controller From Being Damaged. Installing the Spoilboard ················································································ 87-91 Clamping System……………………………………………………………………………………...92 GRBL and Universal G Code Sender Software ················································ 93 Defining the Axes ···························································································...

  • Page 4: Specifications

    Cutting Area: 24" (610 mm) 24" (610 mm) 3.3" (85 mm) The complete E4 parts list can be found in the appendix. Safety is your responsibility. Use the proper protective equipment and "safety sense" when building and operating your CNC Router.

  • Page 5: Getting Started

    Multimeter to correctly connect the power supply and stepper motors. A multimeter is a good tool to have for general electronic trouble shooting. • We recommend using a large flat, clean working surface for assembling your E4. • All screws (unless noted) should be installed snug, then rotated one 1 to 2 1/2 turns.
  • Page 6 Caution: This kit includes small parts that are a choking hazard for small children. Prior and during assembly, keep all parts out of the reach of small children. CAUTION E4 Parts Identification 2mm Allen Wrench 1.5mm Allen Wrench M3 x 10 M2.5 x 16...

  • Page 7: Z Spindle Mount Assembly Instructions

    Z Spindle Mount Assembly Instructions Z Spindle Mount Wood Components Part # Component Frame Mount Support Z Frame Support Z Frame Z Spindle Bottom Mount Z Spindle Top Mount Z Spindle Mount Hardware Part # Qty Hardware Description Coupler Nut Threaded Rod 5/16”...
  • Page 8 . Dry lube is a good lubricant for the dusty environment created when operating Your E4 CNC. Thread the Coupler Nut on the Threaded Rod in the order Step 2 as shown below: Steel Washer >...
  • Page 9 Position second Z Frame Support on top of the washer Step 4 and nut assembly. Set tabs of Z Frame Supports in the corresponding Step 5 Z Frame slots. (The assembly should look like this). Page 9...
  • Page 10 Secure Assembly components with six M4 x 16 Screws Step 6 and Nuts. Apply LOCTITE® to all screws. All screws (unless noted) should be installed snug, then rotated 1 to 2 1/2 turns. Position the nut in “T” of the T-Slot before inserting screws and tightening.
  • Page 11 Place the Z Spindle Bottom Mount into the Z Frame and Step 8 secure with five M4 x 16 Screws and Nuts as shown below. Page 11...
  • Page 12 Step 9 Preparing the DeWalt 660 Rotary Tool for Mounting (see next page for step by step instructions). Page 12...
  • Page 13 Step by Step Instruction for preparing the DeWalt 660 Remove guide base assembly. Remove the Collet Nut. 1. Press and hold down the Spindle Lock. 2. Use wrench to loosen Collet nut. 3. Remove Collet nut (do not discard the collet or the collet nut). Remove the Spindle Cover 1.
  • Page 14 Step 10 Place Z Spindle Top Mount over the DeWalt and slide into position. The top mount must be compressed into the correct position so that the slots on the frame are aligned with the top mount tabs. Note the position of the cord stress relief ( to the left) The DeWalt name plate will be facing up.
  • Page 15 Step 11 Using a M4 Star Driver, reinsert the four original DeWalt screws through the mount into the DeWalt as shown below: Step 12 Place the Frame Mount Supports into the Z Frame and secure each with three M4 x 16 screws and nuts (see below): Page 15...
  • Page 16 Step 13 Secure the Z Spindle Top Mount with two M4 x 16 screws and nuts as shown. Step 14 Install two SG20U Bearings with the M6 x 25 screws, 6mm washers and M6 nuts in the round holes. The bearing hubs must face the wood as illustrated below.
  • Page 17 Step 15 Insert and move the two remaining SG20U Bearings in the elongated holes (photo below right) inward and snug the nuts then rotate 1/4 turn. The nuts will be tightened later when installed on the Y Carriage. Completed Spindle Mount Assembly (back view): Completed Spindle Mount Assembly (front view): Page 17...
  • Page 18 Y Carriage Mount Assembly Instructions Y Carriage Wood Components Part # Qty Component Z Stepper Motor Mount Bearing Bottom Plate Bearing Top Plate Bearing Middle Plate Y Carriage Frame Y Carriage Side Support Belt Retainers Z Rail Stop Z Rail Supports Y Carriage Hardware Y Carriage Bottom Support G H I...
  • Page 19 Try placing 1” strips of blue painters tape behind the T-Slots to help hold the nuts in place. All screws (unless noted) should be installed snug, then rotated 1-1/2 to 2 turns. Apply LOCTITE® to all screws. Step 1 Place Z Rail Support into the Y Carriage Frame and secure with three M4 x 16 Screws and Nuts (see below): Step 2 Place second Z Rail Support into the Y Carriage Frame...
  • Page 20 Step 3 Attach Y Carriage Side Support and secure with five M4 x 16 Screws and Nuts. Step 4 Attach second Y Carriage Side Support and secure with five M4 x 16 Screws and Nuts. Page 20...
  • Page 21 Step 5 Attach Y Carriage Bottom Support and secure with five M4 x 16 Screws and Nuts. Page 21...
  • Page 22 Step 6 Attach Z Rail Stop and secure with two M4 x 16 Screws and Nuts. Page 22...
  • Page 23 Step 7 Attach both Belt Retainers and secure with six M4 x 16 Screws and Nuts. Be sure the tooth profile is on the top, smooth profile on the bottom (see photo below). Page 23...
  • Page 24 Step 8 Install four SG20U Bearings with the M6 x 25 Screws, 6 mm washers, and M6 Nuts . Make sure the hub of the bearing faces the wood. IMPORTANT: the screw must be oriented so that the nut is visible when looking at the back of the carriage (see photo below).
  • Page 25 Notice that there are two round and two elongated holes in the Y Carriage Frame (left photo): round holes Insert screw through the hardened washer then through the plywood hole. Next, put second washer on the screw, then the bearing with the hub against the washer. Last, thread the nut on the screw and snug, then rotate two to four turns.
  • Page 26 The finished installation of the bearings should look like this: The Bearings in the round holes (on top) must be tight. Bearings in the elongated holes should be snug and then rotated 1/4 turn. Page 26...
  • Page 27 Gently insert the two Z Rails through the Z Rail Supports and Step 9 into holes in the Y Carriage Bottom Support. Rotate the rails and thread them through the Z Rail supports. Do not “snap” the rods into the Rail Support. Page 27...
  • Page 28 Step 10 Attach Z Drive to Y Carriage. Slide Z Assembly Bearings over the Z Rails. DO NOT FORCE the SGU20 Bearings over the rods. The SG20U Bearings should roll firmly with a small amount of preload. If needed: Remove the Z Assembly from the rails. •...
  • Page 29 Page 29...
  • Page 30 Step 11 Slide Bearing Bottom Plate over the Threaded Rod, setting tabs in slots. Step 12 Attach the Bearing Bottom Plate and secure with four M4 x 16 Screws and Nuts. Page 30...
  • Page 31 Step 13 Checking Z Thread Rod Alignment As the Router travels up and If necessary, down the Z Axis make sure adjust to center the Threaded Z Rod remains the rod. centered in the hole. Step 14 Attach 5/16 Nuts and Bearing on Threaded Z Rod Thread 5/16 “...
  • Page 32 Slide 8 x 22 x 7 Bearing on Threaded Rod. Thread 5/16” Nut on top of the Bearing. Page 32...
  • Page 33 The 5/16” Nut on top of the bearing should be turned approximately 6 threads down from end of the Z Rod. The nuts on top and below the bearing must be tightened against the bearing as firmly as possible while maintaining the six thread spacing from the end of the threaded rod.
  • Page 34 Step 15 Secure Bearing with Bottom, Middle, and Top Bearing Plates. Slide Z Spindle Mount down rails until nut and bearing assembly rests on Bearing Bottom Mount. Slide Middle Bearing Plate over the Threaded Rod and Bearing. Page 34...
  • Page 35 Slide Top Bearing Plate over the Threaded Rod and Bearing and secure with three M4 x 25 Screws and M4 Nuts. In order to properly retain the bearing securely, evenly tighten screws and nuts in a rotating pattern so that the plywood components are compressed uniformly and tightly together.
  • Page 36 Step 17 Attach Stepper Motor to the Stepper Motor Mount and secure with four M3 x 10 Screws. Apply LOCTITE® to all screws. Page 36...
  • Page 37 Attach Helical Coupler to Stepper Motor Step 16 shaft and Threaded Z Axis Rod Align the milled flat spot on the end of the Threaded Z Rod so that the set screw will be tightened directly against the flat spot. Tighten both set screws with a 2mm Allen Wrench.
  • Page 38 Secure Stepper Motor Mount with four M4 x 16 Screws and Nuts. Page 38...

  • Page 39: Frame Assembly Instructions

    Frame Assembly Instructions X Frame Assembly & Hardware A. M4 x 16 Screws (52) Part # Qty Component Part # Qty Hardware Description B. M4 x 16 Nuts (52) X Rail Support 92 M4 x 16 Screws 92 M4 Nuts Frame Corner Braces X Rail Stops Frame Mid Supports...
  • Page 40 Place the four X Rail Supports onto the Frame Side Step 1 Support and secure each with three M4 x 16 Screws and Nuts. Apply LOCTITE® to all screws. Page 40...
  • Page 41 Repeat procedure with the remaining four X Rail Supports Step 2 and second Frame Side Support and secure each with three M4 x 16 Screws and Nuts. The assembled frames will mirror each other. (See picture below:) Page 41...
  • Page 42 Place the four Frame Corner Brace tabs into the Step 3 corresponding slots as shown and secure each with one M4 X 16 Screw and Nut. Page 42...
  • Page 43 Attach four X Large Corner Supports. Secure each with 2 Step 4 M4 x 16 Screws and Nuts. Page 43...
  • Page 44 Attach both X Cable Mounts to the Frame Mid Supports. Step 5 Secure each with 4 M4 x 16 Screws and Nuts. Page 44...
  • Page 45 Attach X Rail Support Assembly to the completed X Cable Step 6 Mounts. Secure each with four M4 x 16 Screws and Nuts. Attach the two remaining Mid Frame Supports to the X Step 7 Rail Support Assembly. Secure each with four M4 x 16 Screws and Nuts.
  • Page 46 Attach both Frame End Supports and secure each Step 8 side with twelve M4 x 16 Screws and Nuts. Page 46...

  • Page 47: Gantry Assembly Instructions

    Gantry Assembly Instructions Gantry Wood Components & Hardware Part Qty Description Part Qty Description Gantry Frame 67 M4 x 16 Screws Gantry Side Supports 71 M4 Nuts Gantry Corner Braces M4 x 25 Screws Y Rail Supports M6 Nuts Controller Mount 16 M6 Hardened Washers Y Rail Stops M6 x 25 Screws...
  • Page 48 In order to properly complete the next step all five parts must be assembled before attempting to secure them with M4 x 16 screws and nuts. Apply LOCTITE® to all screws. Position the Controller Mount, the four Gantry Back Step 1 Braces and the two Gantry Back Supports and secure with eight M4 x 16 Screws and Nuts.
  • Page 49 Using slots and tabs, set the controller mount assembly on the Gantry Frame and secure with 20 M4 x 16 Screws and Nuts. Page 49...
  • Page 50 IMPORTANT Note the orientation of the Controller Mount below. Note that the hole in the Gantry Frame is accessible because of the cutout in the Controller Mount. Wide spacing for screw holes should be positioned on top. Wide Spacing Page 50...
  • Page 51 Flip the gantry frame assembly over and insert the Step 2 seven Y Rail Supports to the gantry assembly and secure each with three M4 x 16 Screws and Nuts. Page 51...
  • Page 52 Attach Y Stepper Motor Mount and secure with one M4 Step 3. x 16 Screw and Nut. Stepper Motor Mount Page 52...
  • Page 53 Attach Belt Idler Mount and secure with one M4 x 16 Step 4 Screw and Nut. Belt Idler Mount Page 53...
  • Page 54 Attach both Gantry Side Frames and secure each with Step 5 six M4 x 16 Screws and Nuts. Do not install the two fasteners that connect the Gantry Side Frame to the Y Stepper Motor Mount or the Y Belt Idler Mount at this time. Two M4 x 25 Screws with Nuts will be inserted in each piece in a later step: Attach both Gantry Corner Braces and secure each with Step 6...
  • Page 55 Left Side Right Side Page 55...
  • Page 56 Install four SG20U bearings on the inside of both Gantry Step 7 Sides Frames. Snug the bearings in the round holes then rotate two to four turns. Gantry Bearing sequence: Screw head / SG20U Bearing (hub inboard)/ Hardened Washer/Plywood / Hardened Washer /Nut Page 56...
  • Page 57 Move the four SG20U Bearings in the elongated holes Step 8 upward and snug the nuts and rotate 1/4 turn. These will be tightened when installed on the Main Frame. Install three sets of Idler Bearings by inserting a M5 x 25 Step 9 Screw into the Flanged Bearings (keeping the flanges outboard).
  • Page 58 Left Side Right Side Location of Idler Bearings Add Gantry Side Brace and Side Support and secure with Step 10 seven M4 x 16 Screws and Nuts. Repeat for other side. Page 58...
  • Page 59 Gantry Assembly and GT2 Pulley Instructions Parts Required Part # Qty Description Assembled Gantry Stepper Motors Switches Controller 10 Small Zip Ties GT2 Pulleys Spiral Wrap M2.5 x 16 M3 x 10 Screws M2.5 Nuts Install each of the three Stepper Motors and secure Step 1 each with four M3 x 10 Screws.
  • Page 60 Carefully label each Stepper Motor connector so that the correct electrical connections will be made to the controller (see below): Stepper Motor mounting viewed from the back side: Y Stepper Motor X2 Stepper Motor X1 Stepper Motor Insert each of the three GT2 Pulleys into position and Step 2 tighten the set screws.
  • Page 61 Install the X and Y Stepper Motor Home Switches on the Step 3 same side of the Gantry, secure each with two M2.5 x 16 Screws and Nuts in the orientation as shown below . Mark each Home Switch connector so that you will be able to make the proper connection to the controller.
  • Page 62 Carefully wrap the wires with Spiral Wrap then gently Step 4 route them. There are different ways to route the wires, what important is that the wires are properly wrapped and Secured. To avoid false triggering the X, Y and Z Home Switches caused by the electrical noise of the Stepper Motor wires, it is a best practice to secure the Home Switch wires with Spiral Wrap every 5 or 6 turns as shown below: Excess wire can be bundled, then wrapped to...
  • Page 63 Page 63...

  • Page 64: Gantry Installation Instructions

    Gantry Installation Instructions Gantry Wood Components & Hardware Gantry Assembly Frame Assembly 4-Long Rails 4-X Rail Stops 8-M4 x 16 Screws 8-M4 Nuts Place two of the X Rail Stops and secure each with two Step 1 M4 x 16 Screws and Nuts (these will be thoroughly tightened after the GT2 Belts are installed, see below).
  • Page 65 Step 2 Position gantry gently over the main frame. Step 3 Carefully insert the upper rails through the main frame and under the upper pair of SG20U Bearings, through each of the X Rail Supports until the end of the rail is seated in the Frame End Supports .
  • Page 66 Step 4 Carefully insert the lower rails through the main frame and over the bottom pair of SG20U Bearings, through each of the X Rail Supports until the end of the rail is seated in the Frame End Supports. The SG20U Bearings should roll across the rod with a small amount of preload (i.e., they should securely engage the rail and roll firmly).
  • Page 67 If any of the bearings rotate without engaging the rail: • Remove both of the X rods • Loosen the 2 nuts on the slotted holes on each side & slide the SG20U bearings upward • Snug the SG20U bearing nuts •...

  • Page 68: Y Carriage Installation Instructions

    Y Carriage Installation Instructions Parts Required: Part # Qty Description Part # Qty Description Gantry & Frame Assembly M4 x 25 Screws YZ Carriage Assembly M4 x Nuts M2.5 x 16 Screws Y Rail Stops M2.5 Nuts Spiral Wrap Switch Y Rails Page 68...
  • Page 69 Step 1 Insert the top rail through the hole in the Gantry Side Frame and carefully through the Y Rail Supports into the hole of the opposite Gantry Side Frame. Step 2 Carefully hang the upper bearings of the YZ carriage assembly onto the rail.
  • Page 70 The SG20U Bearings should roll across the rail, there should be a small amount of preload (i.e., they should securely engage the rail and roll firmly). Check the bearings to ensure that they are snug up against the rail. The bearing should move along the rail when rotated by hand.
  • Page 71 Step 5 Attach the Z Home Switch to the inside of the Y Carriage Side Support and secure with two M2.5 x 16 Screws and Nuts. Do not overtighten the M2.5 x Screws and Nuts when attaching a switch. Overtightening can cause the switch to fail.
  • Page 72 Step 6 Spiral wrap the Home Switch Wires and zip tie the wrapped wires as shown. Page 72...

  • Page 73: Installing The Belts

    Installing the Belts Parts for assembly include: 1-E4 Assembly 2 -X Belts 1-Y Belt 4-Nylon ties Route the X Belt through the top of the Frame End Support and Step 1 the top slot of the X Rail Stop as shown leaving approximately 2 inches.
  • Page 74 These photos illustrate how the belt wraps around the GT2 Pulley and Idler. Page 74...
  • Page 75 Step 3 Pull the belt through the lower slot on the X Rail Stop. Leave approximately 2-3 inches of the belt extending past the X Rail Stop. While keeping the belt taut, push the X Rail Stop downward to trap the belt. Tighten the two M4 x 16 Screws. Step 4 Loop the belts through the X Rail Stops and Frame End Supports, through the large middle slot and secure the loose...
  • Page 76 Step 5 Route the Y Belt into the Belt Retainer as shown. Step 6 Route the loose end of the Y Belt around the GT2 Pulley and Idler and secure the loose end into the other Belt Retainer. (Be sure the teeth on the Belt engage the teeth on the GT2 Pulley.) Page 76...
  • Page 77 Step 7 Tighten the belt by moving the Idler and tightening the Idler screw and nut (see below). Shorten belt if needed. Page 77...

  • Page 78: Electronic Installation

    Electronics Installation Instructions Parts for assembly include: Part # Qty Description E4 Assembly M4 x 16 Screws M4 Nuts Controller Side Cable Mount Top Cable Mount Bottom Cable Mount Page 78...
  • Page 79 Step 1 Secure the Controller with 4 Small Zip Ties as shown. Be careful not to overtighten which can damage the Controller. Page 79...
  • Page 80 Step 2 Attach Top Cable Mount to top of Y carriage assembly using 2 M4 x 16 Screws and Nuts. Step 3 Attach Bottom Cable Mount to the bottom of the gantry assembly beneath the controller using 2 M4 x 16 Screws and Nuts.
  • Page 81 Step 5 Thread spiral wrapped wiring though Top Cable Mount, secure with a Small Zip Tie. Step 6 Route Z Stepper and Z Home Switch wires and secure with small Zip Tie. Page 81...
  • Page 82 Route X1 Stepper Motor and X and Y Home Switch Wires and Step 7 secure with small Zip Tie. Step 8 Route wires for X2 and Y Stepper Motors and secure with small Zip Tie . Page 82...
  • Page 83 Step 9 Route USB Cable across gantry assembly,down to the Side Cable Mount , then loop to the X Cable Mount and secure with small zip ties. (See below:) Loop the USB cable as shown in order to avoid kinking the cable at the plug end.
  • Page 84 Route the Power Supply and the DeWalt power cord as Step 10 shown and secure in place with Small Zip Ties. Connect the red wire of the Power Supply to the positive(+) terminal on the Controller. Connect the remaining Power Supply wire to the negative (-)terminal on the Controller.
  • Page 85 Tips to keep your controller from being damaged. Always unplug the power supply when connecting or disconnecting the • stepper motor connectors. Make sure all 4 pins are connected for each stepper motor connector. It is • really easy to get the connector offset by one pin. Check and double check your connections before applying power to the •...
  • Page 86 Make sure the Negative (-) is connected to the white or black wire and the Positive (+) is connected to the red or blue wire. Incorrect connections will damage the controller. Note that the X1 Stepper orientation is opposite the others. (the red wire is on the left in the diagram and picture).

  • Page 87: Installing The Spoilboard

    Installing the Spoilboard Parts for assembly include: Part # Qty Description The twelve steel ball bearings are E4 Assembly used as temporary spacers to Wide Base Boards ensure the proper spacing for the Wide Routed T-Slot Boards Routed T-Slot Boards on the Narrow Routed T-Slot Boards Spoilboard.
  • Page 88 Step 2 Gently set first Base Board into position. Be sure the countersinks are facing up. Secure with twelve M4 X 16 Screws. Repeat with the remaining two Base Boards. Page 88...
  • Page 89 Step 2 Tighten all screws and wipe off the surface of the Base Board Assembly to remove any dust or debris to prepare for gluing the T- slot boards. Be sure to test fit the boards before securing with screws. When gluing and setting the T-Slot Boards in place make Step 3 sure the routed slots are facing down...
  • Page 90 Do not use too much wood glue. Spread the glue evenly. Make certain routed slots are clean and glue free. Begin by gluing a narrow T-Slot Board to the left side of the assembly. Place one Steel Ball Bearing as a spacer at each end of the T-Slot channel.
  • Page 91 The Steel Ball Bearings must be used to create the proper spacing between the T-Slot member. Notice the placement of one at each end. Clamp the T-Slot Boards to the Base Boards by taping the ends as shown. We recommend that you place additional weight on the T-Slot Boards until the glue has dried.

  • Page 92: Clamping System

    Clamping System Page 92...

  • Page 93: Grbl And Universal G Code Sender Software

    GRBL and Universal G-code Sender Software • Version 1.1e of GRBL has been uploaded to the controller. • There are several G-code senders for GRBL. I have had success with the Universal G-code Sender Platform Version • Some of the firmware values can be changed from the G-code sender software. Below is a table for the default values uploaded into the firmware from GRBL 1.1e.

  • Page 94: Defining The Axes

    Defining the Axes Axes Definition and Home Locations The E4 CNC Router is set up using the right-hand coordinate system. The arrows in the diagram below display the positive direction for the X, Y, and Z axes. The positive Z axis is up. Once connected, the first operation should be to home the router.

  • Page 95: Tips For Getting Started

    Please check BobsCNC.com for the latest copy. Tips for cutting with the E4 • Always unplug the router before changing the bits • Do not leave the router unattended.

  • Page 96: Appendix

    BobsCNC does not guarantee the buyer’s ability to assemble, setup, or use our product(s). Since the quality of any project produced using the E4 is dependent upon its proper setup and the understanding of its operating parameters, BobsCNC does not guarantee the quality of the parts manufactured using the E4.

  • Page 97: Miscellaneous Parts List

    Miscellaneous Parts List Quantity M3x 10 M4x16 M4 Nuts M4x25 M6x25 M6 Nuts SG20 U Bearings M6 Hardened Washers M5X25 M5 nuts M5 washer Flanged bearings (F625Z) M2.5 x 16 screws M2.5 nuts Wing nuts (1/4-20) 1/4-20 Screws 2" GT2 Pulleys GT2 belt (long) GT2 belt (short) 5/16-18 Threaded Rod...

  • Page 98: Diagram For Plywood Components

    Diagrams for Plywood Components Frame Parts Part # Qty Component X Rail Supports Frame Corner Braces X Rail Stops Frame Mid Supports Frame Side Support Frame End Supports X Cable Mounts Large Corner Braces Page 98...
  • Page 99 Diagrams for Plywood Components Gantry Parts Part # Qty Component Part # Qty Component Gantry Frame Y Stepper Motor Mount Gantry Side Supports Y Belt Idler Mount Y rail Supports Gantry Corner Braces Controller Mount Y Rail Stops Gantry Back Braces Gantry Side Braces Gantry Back Supports Gantry Side Frames...
  • Page 100 Part # Qty Component Side Cable Mount Bottom Cable Mount Top Cable Mount Page 100...
  • Page 101 Diagrams for Plywood Components Y Carriage Parts Part # Qty Component Z Stepper Motor Mount Bearing Bottom Plate Bearing Top Plate Bearing Middle Plate Y Carriage Frame Y Carriage Side Supports Belt Retainers Z Rail Stops Z Rail Supports Y Carriage Bottom Support Page 101...
  • Page 102 Diagrams for Plywood Components Z Parts Part # Component Frame Mount Support Z Frame Support Z Frame Z Spindle Bottom Mount Z Spindle Top Mount Accessories Part # Component Short Clamp Long Clamp Wrench Page 102...
