Network ports LED
Show status for devices
that are connected to
AL59300 by cable.
LED for nettverksport
Viser status for enheter som
er tilkoblet til AL59300
med kabel.
WAN LED
LED that show status
for the WAN port on the AL59300.
The LED will flash when port is active.
WAN LED
LED som viser status for WAN
porten. LED blinker når det er
aktivitet på WAN porten.
Air:Link 59300

Installation Guide

Power LED
Strøm LED
WLAN LED
LED that show status
for the wireless radio.
The LED will flash when active.
WLAN LED
LED som viser status for
det trådløse nettverket.
LED blinker ved aktivtet.
Power connector
Strømtilkobling
WAN port
Please connect your
broadband modem
to the internet port.
WAN port
Koble ditt bredbånds-
modem til internet porten
på AL59300.
Network ports
Ports for connecting network
devices by cable, such as computer,
TV, Media Server, Network printer,
VOIP adapter etc.
Nettverksporter
Porter for tilkobling av
nettverksenheter via kabel.
Eksempelvis datamaskin,
TV, Mediaserver, nettverksprinter,
VOIP adapter osv.
Reset / WPS*
Reset: Hold for about 10 seconds to
reset AL59300 to factory default.
WPS: Hold for about to 2-3 seconds
to initiate WPS connection.
* WPS is disabled as default
and needed to be activated in
router GUI (http://192.168.38.1) before
use.
Reset / WPS*
Reset: Hold knappen inne i ca. 10
sekunder for å nullstille AL59300.
WPS: Hold knappen inne i 2-3 sekunder
for å starte en WPS tilkobling.
* WPS er deaktivert som standard og
må aktiveres i rutermenyen
(http://192.168.38.1) før den kan benyttes.
