Honeywell PPMINI User Manual

Additional Information
Specifications
System
Frequency range: 2.400~2.483GHz (16 channels and 65535 ID per channel)
Remote range: Approx. 66 feet (20 meters) line of sight
Operating voltage: 2.6V~3.3V
Power: One CR2032 lithium battery (3V)
Output power: Under 1mW
Very low power consumption: Normal operation <5mA, Laser operation < 20mA, Sleep <10uA
Physical Dimensions
Size: Transmitter: 66(l) x 40(w) x 14 (h) mm ; Receiver: 33.6(l) x 16(w) x 3.5 (h) mm
Weight(Approx.): Transmitter: 24. grams (include battery) ; Receiver: 1.6 grams
Environmental Requirements
Temperature: Operating: 0ºC (32ºF)~60ºC (140ºF) Non-operating: -10ºC(14ºF)~65ºC(149ºF)
Humidity : Operating: 10%~85% RH
(non-condensing)
λ
Laser: Semiconductor laser ( = 650 nm), emission duration: continuous
Laser output power: Max. 0.95mW
Note: Note: Design and specifications are subject to change without notice.
Appendix A Regulatory Compliance
FEDERAL COMMUNICATIONS COMMISSION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiated radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.
Patent Pending
RoHS
Doc No.: EB-B8010-201
Non-operating:10%~95%RH
13475 Danielson Street, Suite 120
Poway, California 92064
Tel: 858-513-6391 Fax: 858-513-9352
E-mail : info@powerr mote.com e
©
Copyright 200 Honeywell International Inc. 8
www.powerremote.com
4
MINI POWER PRESENTER

User Manual

Please read this User Manual carefully to familiarize yourself with the proper operation of your new
Honeywell Mini Power Presenter and keep these instructions for future reference.
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without
the express written prior permission of the Honeywell International Inc.
The manufacturer provides this document without warranty, or condition of any kind. The manufacturer may
make improvements or changes to the product described in this documentation at any time.
Other product and company names herein may be the trademarks of their respective owners.
IMPORTANT SAFETY AND HEAL TH INFORMATION
WARNING! RISK OF INJURY!
Laser light can cause permanent damage to eyes. Laser light can cause permanent damage to eyes. Do not look into
the laser beam or shine the laser beam into your eyes, other
' '
peoples eyes, or pet s eyes.
Keep this device away from Children. This is a working tool, not a
toy or entertainment device. It should only be used by adults.
Introduction
Benefits
Easily control the pace of your presentation
With the Honeywell Mini Power Presenter, there is no need to stand beside you computer or have an
additional person click the slides for you, nor do you need to aim the remote at the Radio Frequency
receiver.
Slim, compact and easy to carry
Honeywell's Mini Power Presenter is a specially designed presentation tool, its USB dongle is
designed small enough to snap into and store in the main body.
Multi -function
Honeywell's Mini Power Presenter is a combination of RF wireless control for PowerPoint and
other presentation software providing keyboard shortcuts and a laser pointer. The device enables
the user to control presentation slides wirelessly up to 66 feet (20 meters) away line of sight.
Easy to use
Honeywell's Mini Power Presenter is a USB plug-and-play device with no additional software
required.
1
