- Page 1 VISTEK V1667, V1667/SY & V1667/SY-VHS 12-BIT PAL/NTSC TO SDI ADAPTIVE COMB FILTER DECODER USER GUIDE www.pro-bel.com...
-
Page 2: Table Of Contents
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder Contents GENERAL DESCRIPTION ..................4 INSTALLATION ......................5 2.1 Rear Panel Layout and Signal Connections..........5 2.2 Frame Synchroniser Module (Optional)............6 2.3 Frame Synchroniser Delay................6 2.4 Insertion Delay .................... - Page 3 VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder 8.4 An Introduction to Vislock Processing............18 8.4.1 What is VisLock? ................18 8.4.2 How does it work?................18 8.4.3 Does the added data degrade my picture? ......... 19 8.4.4...
-
Page 4: General Description
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder GENERAL DESCRIPTION The V1667 is a 12 bit broadcast quality multi-standard adaptive comb filter decoder, and forms part of the Vistek V1600 modular range of interface products. The 3U x 250mm card may be fitted into either the V1601 (1U) or V1603 (3U) 19”... -
Page 5: Installation
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder INSTALLATION Rear Panel Layout and Signal Connections SDI Output 1 (IN) SD 1 SDI Output 2 (OUT) SDI Output 3 SD 2 SD 3 SDI Output 4... -
Page 6: Frame Synchroniser Module (Optional)
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder Frame Synchroniser Module (Optional) A Frame Synchroniser module may be optionally fitted to the V1667. It is located into sockets P1, P2, P3 and P4. Its presence is automatically detected by the on board micro-processor and is consequently integrated into the signal processing path. -
Page 7: Front Panel Layout
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder FRONT PANEL LAYOUT See Section 8.3 VHS Input Option for a description of the VHS decoding option. Remote Control Access and Power indicators NTSC Standard and Page indicators AUTO Std. -
Page 8: Page/Parameter Map
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder Page/Parameter Map This table shows all the adjustable Parameters in each Page. It may be convenient to keep a copy close to the equipment. Top Page Page 1 (SIG) -
Page 9: Front Panel Description (Normal Operation)
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder FRONT PANEL DESCRIPTION (NORMAL OPERATION) See Section 8.3 VHS Input Option for a description of the VHS decoding option. +V Indicator This is a green LED that is illuminated when the module is powered. -
Page 10: Remote / Local Switch
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder Adjustment of the video standard (Standard) is described in the section entitled 4.3 Video Standard Indicators / Selection of Video Standard. Video gain (VGain) may be increased by pressing the Up button (▲) or reduced by pressing the Down button (▼) . -
Page 11: Timing Page (Frame Synchroniser)
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder TIMING PAGE (FRAME SYNCHRONISER) See Section 8.3 VHS Input Option for a description of the VHS decoding option. Timing Page Entry Press the Select button and hold in, followed by the Down (▼) button. Entry to the Timing Page will occur immediately, and will be indicated by the Tim pair of LEDs (PAL M and 443) flashing simultaneously. -
Page 12: Timing
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder The Frame Synchroniser offers three modes of operation when the input signal fails/disappears (Sync Fail Mode). These are: Sync Fail Mode (▲) Freeze picture. Cal. Freeze picture for 3 seconds, then cut to black (▼) -
Page 13: Engineering Page
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder ENGINEERING PAGE See section 8.3 VHS Input Option for a description of the VHS decoding option. Engineering Page Entry Press the Select button and hold in, followed by the Down (▼) button. Keep both buttons depressed for 5 seconds until all six yellow standard LEDs become illuminated simultaneously. -
Page 14: Engineering
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder Engineering Page Exit Press the Select button, followed by the Down (▼) button. The decoder will exit the Engineering Page immediately, and resume normal front panel operation. If the unit is left in the engineering page for more than five minutes, during which no button has been pressed, then the decoder will timeout from this page and revert to normal front panel operation. -
Page 15: Technical Specification
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder TECHNICAL SPECIFICATION Analogue Input (Looping) Format PAL B, G, I, M, N, NTSC M, NTSC Japan, NTSC 443 Level 1V p-p composite (terminated) Connector Impedance 75Ω (external) Return loss >... -
Page 16: Appendix
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder APPENDIX On Board Adjustable Components Circuit Reference Description Syncs to picture timing alignment. 625/525 line standard discrimination. Luminance gain alignment:- 525 input Luminance gain alignment:- 625 input Note: The table above is included for information only. -
Page 17: Vhs Input Option
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder VHS Input Option This option is available ONLY on the V1667/SY–VHS product. Analogue Composite 10 bit parallel DEC 1 Video Input D1 data 12 bit adaptive to D1... -
Page 18: Parameter Selection And Adjustment
VISTEK V1667, V1667/SY & V1667/SY-VHS 12-bit pal/ntsc to sdi adaptive comb filter decoder 8.3.2 Parameter Selection and Adjustment This table shows all the adjustable Parameters in each Page when in VHS decode mode. Top Page Page 1 (SIG) Page 2 (TIM) Page 3 (ANC) ENG. -
Page 19: Does The Added Data Degrade My Picture
8.4.5 How is VisLock Implemented? The Vistek V1667 decoder and V1668 encoder modules are now available with VisLock, no additional equipment is required. The V1667 decoder converts the NTSC to serial digital (SDI) format and inserts the VisLock data. When the serial digital signal is subsequently converted back to NTSC in a VisLock compatible V1668 encoder the added data is read and the signal timed to ensure that optimum encoding quality is achieved and the signal timed to the genlock reference signal.
