Summary of Contents for pro bel 3417
-
Page 1: Table Of Contents
3417 HDTV Digital to Analogue Converter Contents Introduction Installation I/O connections Configuration Local card edge controls Setting the output mode Setting the pattern generator mode Selecting the pattern lock source Selecting local/remote operation DIL switch control summary Factory pre-set controls... -
Page 2: Introduction
3417 Introduction The 3417 is an HDTV digital to analogue converter designed to be used in the ICON series of 1RU or 3RU frames. It offers Y, Pb, Pr analogue outputs or SVGA output and two reclocked HD-SDI outputs. It handles interlaced serial digital signals of 1.485Gb/s and 1.485/1.001 Gb/s conforming to SMPTE specification 292M - 1080i 30Hz and 1080i 30/1.001 Hz. - Page 3 3417 HDTV Digital to Analogue Converter chapter 1 Technical Manual...
-
Page 4: Installation
3417 Installation The 3417 HDTV digital to analogue converter fits in the 1050 3U and 1051 1U ICON modular product rackframes. RV 5 +5VA +5VC CABLE +5VD 3417 LENGTH +5VE ADJUST +5VF +3V3 +5VF TP10 STATUS 1 STATUS 2 RV 4... -
Page 5: I/O Connections
HDTV Digital to Analogue Converter I/O connections The 3417 is used with the 30mm K3417-3 rear connector. The HDTV input uses one BNC whilst re-clocked versions of the input are available on two further BNCs. Component outputs provided comprise Y, Pb and Pr on BNCs and an SVGA monitor feed on a 15 pin high density connector. -
Page 6: Configuration
DIL switch settings control the following output and pattern generator modes: Setting the output mode The 3417 may be used in either the Y, Pb, Pr mode or the VGA mode. Make the selection with front edge DIL switch 0 as shown in the following diagram:... -
Page 7: Dil Switch Control Summary
3417 HDTV Digital to Analogue Converter DIL switch control summary The available switch settings are summarised in the following table: Switch settings DIL lever Function ON = VGA mode, OFF = Y,Pr,Pb mode ON = pattern generator mode, OFF = DAC mode... -
Page 8: Adjusting The Analogue Video Output
3417 Adjusting the analogue video output Individual adjustments are provided for Y, Pb and Pr output amplitude. These adjustments are pre-set at the factory and should not require re-adjustment. Access to these controls, which are sited near the module edge connector, is not normally available with the card fitted in a rackframe. - Page 9 3417 HDTV Digital to Analogue Converter chapter 3 Technical Manual...
-
Page 10: Status Monitoring
• module present • module type • module bar code • module issue no For further details of the Pro-Bel status monitoring system please refer to the COSMOS status monitoring manual. chapter 4 Issue 1.0... - Page 11 3417 HDTV Digital to Analogue Converter chapter 4 Technical Manual...
-
Page 12: Trouble Shooting
RV1 may require the card to be returned to the factory NOTE: Two 3417 modules may be used to analyse signal paths by using one as a source in pattern generator mode and the other as a test receiver with the TTL output monitored on an oscilloscope. - Page 13 Lights yellow to show that the module is in remote mode POWER OK Lights green if all voltage rails are present Indicates detected input mode. The 3417 will only work in the 1080i 30 Hz mode STATUS 1-4 and 1080i 30/1.001 Hz mode (Status LED 4 ON)
- Page 14 1080P 30 Hz and 30/1.001 Hz Invalid 1080P 25Hz Invalid 1080P 24Hz and 24/1.001 Hz Progressive (Unknown) 1080i 30 and 30/1.001 Hz (3417 mode) Invalid 1080i 25Hz F Invalid 1080i 25Hz C Invalid 1035i 30 Hz and 30/1.001 Hz Unknown chapter 5 Issue 1.0...
- Page 15 3417 HDTV Digital to Analogue Converter chapter 5 Technical Manual...
-
Page 16: Specification
3417 Specification Inputs Number and type: One HDTV serial digital video input to SMPTE 292M, 1080i 30 Hz and 1080i 30/1.001 Hz Impedance: 75W unbalanced Signal outputs Number and type: Two as input equalised and re-clocked HDTV analogue to SMPTE 274M, 1 each of Y, Pb, Pr SVGA output in RGBHV format at 33.75kHz... - Page 17 3417 HDTV Digital to Analogue Converter chapter 6 Technical Manual...
-
Page 18: Ordering Information
3417 Ordering information Part number Description HDTV Digital to Analogue Converter, 30mm ICO-3417-3000 chapter 7 Issue 1.0...
