Summary of Contents for pro bel 4410
-
Page 1: Table Of Contents
Contents Introduction Installation Selecting a rear connector Configuration Setting reference options Configuring the AES reference Configuring Video/Wordclock references Setting the sample rate Setting Full Scale Digital level Setting the reference oscillator Trouble shooting COSMOS Status Monitoring Specification Ordering information 4410... -
Page 2: Introduction
Audio Analogue to Digital Converter Introduction The 4410 module is an audio analogue to digital converter which may be fitted with one or two stereo ADC sub-boards, each providing four balanced or unbalanced digital outputs to AES3-1992. The digital outputs can be configured to lock to one of three references, video, wordclock or any valid balanced or unbalanced AES signal. - Page 3 Technical Manual 4410...
-
Page 4: Installation
Audio Analogue to Digital Converter Installation For module installation instructions please refer to the appropriate ICON rack frame section of the manual 2.1 Selecting a rear connector There are two alternative rear connectors provided. The K4410.3B is used for balanced signals, whilst the K4410.3U is used for unbalanced signals. Both occupy 30mm of rack width in the 1050 3U Icon rack frame. - Page 5 OP1- OP2- AUDL1+ AUDL1- 0P1-+ OP2+ AUDR1+ AUDR1- OP1- OP2- Not used Not used 0P1+ OP2+ AUDL2+ Not used AES REF IP - AUDL2- Not used AES REF IP+ AUDR2+ AUDR2- OP2- OP1- OP2+ OP1+ OP2- OP1- OP2+ OP1+ 4410...
-
Page 6: Configuration
Configuration 3.1 Setting reference options The 4410 digital audio encoder may be locked to one of three types of reference signal, analogue video, wordclock or any valid AES 11 signal. When locked to video, the line standard may be selected for 525 or 625 lines. In addition, the sample rate may be selected as 32kHz, 44.1kHz and 48kHz. -
Page 7: Configuring The Aes Reference
Jumper PL7 is used to terminate this input with 75 W, however this termination will need to be removed for bridging or looping purposes. RSF1 HI-Z TERM I/P1 Set PL7 to Term for 75W termination Set PL7 to Hi-Z for looping or bridging reference configuration 4410... -
Page 8: Setting The Sample Rate
Audio Analogue to Digital Converter 3.4 Setting the sample rate The sample rate may be selected as 32kHz, 44.1kHz or 48kHz by using front edge mounted switch SW2. The appropriate card edge sample rate LEDs will illuminate (green) to confirm the selection. Setting the sample rate Jumper Function... -
Page 9: Setting The Reference Oscillator
Technical Manual 3.6 Setting the reference oscillator The free-run speed of the reference oscillator may be set with RV1 on the 4410 module. PL 5 12 LOCK 13 LOCK LOSS OF I/P INVALID SAMPLE RATE SW1-1 SW1-2 SW1-3 SW1-4 SW2-1... -
Page 10: Trouble Shooting
Note: It is recommended to employ a common station video reference or a common AES11 reference for all digital audio equipment if accurate phasing to station signals is required throughout a facility. The 4410 should meet the timing requirements of AES11 under these conditions. -
Page 11: Status Indicators
INVALID Invalid reference Lights red to Indicate invalid AES 11 reference POWER Power OK Lights green if all voltage rails present 48kHz sample rate selected SAMPLE 44.1kHz sample rate selected RATE 32kHz sample rate selected 4410 status indicator assignments 4410... -
Page 12: Cosmos Status Monitoring
Audio Analogue to Digital Converter COSMOS Status Monitoring If the frame is equipped with a COSMOS controller card, the following parameters will be reported back to the COSMOS status monitoring system. • module present • reference video present • reference video not locked •... - Page 13 Technical Manual 4410...
-
Page 14: Specification
Audio Analogue to Digital Converter Specification Inputs (per sub-module) Number and type: 2, balanced, floating, analogue audio Impedance: 20kW, 20Hz to 20 kHz (as per 5124) Level for 0dB FSD: +15dBu to +24dBu Reference: AES 11 1997, balanced or unbalanced or Analogue video, 525/626 1V pp or Wordclock 1V pp Outputs (per sub-module) - Page 15 Loss of input: Red LED Reference video present: Green LED Video not locked: Red LED AES 11 presentGreen LED AES locked: Green LED Sample rate: Yellow LEDs, 48, 44.1 and 32KHz Temperature range Operating:0° to +40°C Storage:-10°C to +70°C 4410...
-
Page 16: Ordering Information
Audio Analogue to Digital Converter Ordering information ICO-4410-3BHS: Audio ADC with 30mm rear panel, balanced AES3 outputs, peak level +24dBu, single stereo converter ICO-4410-3BHD: Audio ADC with 30mm rear panel, balanced AES3 outputs, peak level +24dBu, dual stereo converter ICO-4410-3BLS:...
