- Page 1 NEXT ImageQuest L530 T F T L C D Color Monitor User's Guide Click www.hyundaiQ.com...
- Page 2 BACK U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION NEXT RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 BACK DECLARATION OF CONFORMITY NEXT ImageQuest CO., LTD. Ami-ri Bubal-Eub Ichon-Si Kyungki-Do 467-860 KOREA declare under our sole responsibility that the product: Kind of equipment COLOR MONITOR Type-Designation L15D0C060 to which this declaration relates is in conformity with the following standard(s) or other normative document(s)
-
Page 4: Table Of Contents
BACK L530 15" TFT Digital LCD Monitor NEXT Contents 1. Introduction .......1/15 2. Safety Information ....1/15 3. Installing the monitor ....4/15 3-1. Packing List ........4/15 3-2. Selecting a suitable location ..5/15 3-3. Connecting the monitor ....5/15 3-4. Setting the refresh rate ....7/15 Preset Timing Table .......8/15... -
Page 5: Introduction
BACK L530 15" TFT Digital LCD Monitor NEXT 1. Introduction This manual contains instructions for installing and operating ImageQuest L530. ImageQuest L530 is a highly ergonomic color display unit. • 15" viewable XGA LCD • Supporting full scan flicker-free picture quality •... - Page 6 BACK L530 15" TFT Digital LCD Monitor NEXT Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected. Overloaded AC outlets and extension cords are dangerous, as are frayed power cords and broken plugs, which may cause electric shock or fire.
- Page 7 BACK L530 15" TFT Digital LCD Monitor NEXT Cleaning and Maintenance • To avoid risk of electric shock, do not disassemble the display unit cabinet. The unit is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning.
-
Page 8: Installing The Monitor
BACK L530 15" TFT Digital LCD Monitor NEXT 3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Japan Power Cord American/Canada Europe DVI-D Cable South Africa Australia Compact Disc Korea AC/DC Power adapter Above power cord can be changed upon different voltage areas. -
Page 9: Selecting A Suitable Location
BACK L530 15" TFT Digital LCD Monitor NEXT 3-2. Selecting a suitable location • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. • Place the monitor in a position where no light shines directly onto or is reflected on the screen. - Page 10 BACK L530 15" TFT Digital LCD Monitor NEXT Turn on the power to the computer. The picture will appear within about 10 seconds. Adjust the picture to obtain optimum picture quality. See section Adjusting the picture in this guide for more information.
-
Page 11: Setting The Refresh Rate
BACK L530 15" TFT Digital LCD Monitor NEXT LED Indicator Soft Power Switch 3-4. Setting the refresh Follow the instructions below to set your refresh rate in Windows 98. rate Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. -
Page 12: Preset Timing Table
BACK L530 15" TFT Digital LCD Monitor NEXT Preset Timing Table If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user guide of videocard because the screen may not be displayed. -
Page 13: Adjusting The Picture
BACK L530 15" TFT Digital LCD Monitor NEXT 4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. 1024X768 V:60.4/H:48.7 Brightness Contrast Flesh Tone Misc Recall 9/15... -
Page 14: Using The On Screen Display
BACK L530 15" TFT Digital LCD Monitor NEXT 4-1. Using the On Screen Push the MENU button to call the OSD to the screen. The resolution and Display frequency are displayed at the top of the menu box for your information. -
Page 15: Osd Adjustments
BACK L530 15" TFT Digital LCD Monitor NEXT 4-3. OSD Adjustments The OSD adjustments available to you are listed below. BRIGHTNESS You can play the movie Adjust the brightness of the screen. file to see how to adjust the picture image by... -
Page 16: Display Power Management
BACK L530 15" TFT Digital LCD Monitor NEXT 5. Display power If the power management function of your computer is enabled, your monitor management turns on and off automatically. You can control power management features from your computer. Reducing power... -
Page 17: Troubleshooting
BACK L530 15" TFT Digital LCD Monitor NEXT 6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by reading followings. Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on. - Page 18 BACK L530 15" TFT Digital LCD Monitor NEXT Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Duplicated A problem with your graphics adapter or display unit. Contact your images service representative.
-
Page 19: Specifications
BACK L530 15" TFT Digital LCD Monitor 7. Specifications 15"viewable, Diagonal Dot pitch 0.297 mm, AM-TFT Brightness 180cd/m (Min.), 200cd/m (Typ.) Response Time 40msec Display area 304 X 228 mm Number of color 16,7 million colors (with dithering) Input signals T.M.D.S Digital Sync, 24 pin DVI-D...
