SAFETY PRECAUTIONS

Please read this instruction manual carefully before assembling and operating this model.
• This product is an authentic radio controlled model, not a toy.
• To enjoy this model to the fullest, properly assemble the model before operating it, perform maintenance after each operating session, and replace some parts with optional parts.
• Improper usage of rechargeable batteries may make the electric current too high, which may cause heat, liquid leakage, and or fire. Follow the battery and charger
instruction manuals and use both items safely.
WARNING!
In order to operate the model safely, adhere to following instructions. Hear are some possibilities of significant damage to life and or body, if the following explanation.
• Before you start assembling this model, read this instruction manual thoroughly. If you are not used to assembling a model, seek advice from people who have enough
experience in assembling models and assemble this model correctly.
• This product includes many small or sharp parts, so be careful with them and keep them out of the reach of small children.
• All tools including knives, pliers and drivers require careful handling to avoid injury.
• Painting must be done only in a well-ventilated area.
• With weak or dry batteries, the radio will not be able to control the model and the model may become out of control and cause a serious accident. Always be aware
how much power is left in radio batteries and charge or replace them with new ones if necessary.
• Don't operate the model on anything except the track designed exclusively for it.
• Be sure that you are not operating this model at a place where there is another model running at the same frequency as yours. Failure to do so will cause the models to lose control.
• When the model is moving strangely, stop the model immediately and find out the reason. Don't operate the model again until the problem is solved. To continue
operating the model without solving the problem may lead to further trouble or unforeseen accidents!
• Don't put fingers or any objects inside the rotating or moving parts!
• Always operate the model attached with a body shell (not included in the kit).
• Check all screws and nuts on a regular basis for looseness.
• To avoid damage, don't install any optional parts not made by INFINITY in this model or modify the model.

ITEMS REQUIRED FOR OPERATION

1. Transmitter and Receiver (2ch)
2. Low-Profile Steering Servo
3. Speed Controller
4. 540 size Motor
5. LiPo Battery (7.4V, Hard plastic case)
6. LiPo Battery Charger
7. Tires, Wheels and Inserts for 1/10 Formula car.
PROHIBITED
8. 1/10 Formula Body Shell
9. 1/10 Formula Wing
10. Polycarbonate Paint
11. 64 Pitch Pinion Gear
12. Silicone Oils
13. Graphite Grease
14. Ball DIff Grease

TOOLS REQUIRED

1. Hex Wrenches (1.5mm / 2.0mm / 2.5mm / 3.0mm)
2. Box Driver (5.0mm / 5.5mm / 7.0mm)
3. Needle Nose Pliers
4. Nippers for plastic parts
5. Sharp Hobby Knifes
6. Scissors
7. Turnbuckle wrench (4.0mm)
8. Body Reamer
