ESP8266User Manual
serial port and repeat Step 2 and Step 3.
Step 7: select and download next bin file which you are going to burn into the
flash, for example, eagle.app.v6.irom0text.bin.
Note: the corresponding Program Address Offset for eagle.app.v6.irom0text.bin
is 0x40000. Please refer to bin directory descriptions in "4.2 Directory Structure".
Step 8: close serial port
After the downloading, users can check and print relevant information with
SecureCRT.
Set the jumper on the motherboard as MTDO：0，GPIO0：1，GPIO2：1, then it
will enter operatings mode.
Note: please disconnect the power when setting the jumpers.
11 / 13Espressif SystemsJune 19, 2014
