SECTION 4. INSTALLING THE
CONVERSION KIT
This section describes the installation of the Entelliguard,
MicroVersaTrip Plus and MicroVersaTrip PM and conversion
kit. The components provided with the kit are shown in Fig 2.
Wiring Harness
Flux Shifter
Assembly
Connector
Hardware
Current Sensor
(LA4000-Blue)
Figure 2: Components supplied with the conversion kit
5
Mounting Plate
Programmer
Bracket Assembly
Trip Unit
