Hyundai IONIQ Hybrid 2017 Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
How to Defrost - page 24-25
1 Press the front defrost button.
Set to warmest temperature setting.
2
Set to highest fan speed.
3
☐
Tire Pressure Monitoring System (TPMS) - page 36
LOW TIRE PRESSURE INDICATOR /
TPMS MALFUNCTION INDICATOR
NOTE: Tire pressure may vary in colder temperatures causing the low
tire pressure indicator to illuminate. Inflate tires according to the Tire
Pressure Label located on the driver's side door pillar.
☐
Windshield Wiper / Washer - page 10
MIST
• To activate wipers, move the switch down
to one of the three positions (INT, LO, HI).
OFF
• To adjust "INT" speed, move switch.
INT
• To spray washer fluid, pull lever toward you.
LO
• Push lever up for a single wiper pass.
HI
☐
Unlocking vehicle - page 02
LOCK
UNLOCK
LIFTGATE UNLOCK
PANIC
☐
BLUE LINK - pages 31-33
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
- Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
MAINTENANCE
Scheduled Maintenance Normal Usage
Engine Oil and Filter* Replace 7,500 or 12 mos.
Fuel Additive Add 7,500 or 12 mos.
Tire Rotation Perform 7,500
Inspect 7,500
Air Cleaner Filter
30,000
Replace
Vacuum Hose Inspect 7,500
Climate Control Air Filter
Replace 15,000
(for Evaporator and Blower Unit)
Air Conditioning Refrigerant Inspect 15,000
Brake Hoses & Lines Inspect 15,000
Drive Shafts & Boots Inspect 15,000
Exhaust Pipe & Muffler Inspect 15,000
Front Disc Brake/Pads, Calipers & Rotors Inspect 15,000
Rear Brake Disc/Pads Inspect 15,000
Steering Gear Box, Linkage & Boots/
Inspect 15,000
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts Inspect 15,000
Brake Fluid Inspect 30,000
Engine Clutch Actuator Fluid Replace 22,500
Crankcase Ventilation Hose Inspect 30,000
Fuel Filter Inspect 30,000
Fuel Lines, Fuel Hoses and Connections Inspect 30,000
Fuel Tank Air Filter Inspect 30,000
Parking Brake Inspect 30,000
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 30,000
Spark Plugs Replace 105,000
Inspect 7,500 or 12 mos.
HSG Belt
Replace 60,000 or 48 mos.
1st Replace 120,000 or 120 mos.
Coolant
Add'l Replace 30,000 or 24 mos.
Dual Clutch Transmission Fluid Inspect 37,500
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner's Manual for details.
Looking For more detailed information? This Quick Reference Guide does not replace your vehicle's
Owner's Manual. If you require additional information or are unsure of a specific issue, we
recommend that you always refer to the vehicle's Owner's Manual or contact your authorized
Hyundai dealer. The information contained in this Quick Reference Guide is correct at the time of
printing; however, specifications and equipment can change without notice. No warranty or
guarantee is being extended in this Quick Reference Guide, and Hyundai reserves the right to
change product specifications and equipment at any time without incurring obligations. Some
vehicles are shown with optional equipment.
Severe Usage*
Replace 3,750 or 6 mos.
Add Same as Normal
Perform Same as Normal
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect 7,500
Inspect Same As Normal
Inspect More Frequently
Inspect More Frequently
Inspect More Frequently
Inspect Same As Normal
Inspect Same As Normal
Replace Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Replace More Frequently
Replace Same As Normal
Replace More Frequently
Inspect 3,750 or 6 mos.
Replace 30,000 or 24 mos.
Replace Same As Normal
Replace 75,000
IONIQ HYBRID
HYUNDAI
Quick Reference Guide
NP150-AE172
(Rev 02/04/17)
Printing 02/07/17
www.hyundai.com
1-800-243-7766
Roadside Assistance:
1-800-633-5151
Consumer Affairs:
XM ® Radio: 1-800-967-2346
Sirius
1-855-2BLUELINK
Blue Link:
(1-855-225-8354)
