EMPORIA SOLIDplus V33i Short Manual

TOOLS

Position
Your mobile phone has a GPS unit (Global Positioning System)
to support the emergency function. This feature allows to
locate the mobile phone worldwide, and to determine your
exact location.
Note: The enabled position determination requires a lot of
electricity, thereby reducing the operating time of mobile
phone in continuous operation to 36 hours.
Note: The GPS functionality is inside buildings can not be
guaranteed. If after a few minutes, you still have no position,
check if you have a direct view to the sky (satellites), and/or
go away from high walls of buildings.
Note: Rescue organizations will receive the positioning GPS
coordinates. Recipients will receive a private google maps link.
Note: If your device is not able to receive a GPS signal, the last
saved position will be automatically sent with an appropriate
notice.
Enable/Disable positioning: enter menu Tools
enter Position with Position on/off
Share your position with friends:
Selected contacts have the opportunity to your current
position interrogate another mobile phone.
These contacts are defi ned in your Friends list.
Do not worry: numbers that are not on this list can not
determine your position.
Go to Tools Position Show friend list to see which of
your contacts is it allowed to check your position.
Note: To enter, delete or edit the Friends list please contact your
service provider.
Bluetooth
Enable/Disable Bluetooth: enter menu Tools
enter Bluetooth with Bluetooth on/off
Pairing devices: enter menu Tools
enter Bluetooth with Connections
Search for new devices to search for available devices
choose the desired device confi rm with .
Paired devices are automatically recognized the next time,
if they are in range.
Alarm
Press in standby mode
New time: enable alarm clock enter time
confi rm with .
The alarm clock rings every day at this time.
Off : disable alarm clock
Press to stop an ringing alarm.
Mute an ringing alam by pressing (rings again in a minute).

FREQUENTLY ASKED QUESTIONS

The mobile phone is not responding:
Remove battery, re-insert and switch on the device.
If still no response, please contact the Service Center.
The charging process will not start:
It may take a few minutes. If no response after 10 minutes,
please contact the Service Center.

EMPORIA EMERGENCY BUTTON

You can store up to 5 emergency numbers (family, neighbours,
friends, emergency services).
In case of an emergency press the emergency button on the
reverse side of the mobile telephone either for 3 seconds or
3 times within 3 seconds. The emergency key will still work
when the key lock is enabled.
By pressing the emergency button the emergency sequence
is started. Up to 5 numbers will be called in a predetermined
order until someone answers the emergency call.
This process is repeated 3 times.
If no emergency number is defi ned, your prepaid-card is
out of charge or you are outside of the home network of
your network operator, the international emergency
number 112 will be called.
During the emergency sequence a warning tone is played
back, to inform the people around you about the emergency.
PleaseNote: By answering the emergency call, the called
person have to dial the 3 times, during the first minute of
the call. (Dialing the 3 x by the receiver of the call ensures
that your emergency call is not forwarded to an answering
machine or voicemail).
Parallel to the emergency calls in the background, your
position is determined. If this information is available, a text
message will be sent to all emergency numbers, including
your current location or address (Google-Maps-Link).
Through the use of network services (emergency SMS) may
incur charges.
Saving emergency numbers:
Go to Phone book Emergency numbers
Add Emerg. No choose EmNo. (1-5) specify whether it
is a Private number or a Helporganisation
choose a contact in Phone book fi nished
PleaseNote: If you choose Private number the receiver have to
dial 3x . By a Helporganisation, a recall is not required.
Enable the emergency button:
Go to Phone book Emergency numbers
Emergency button On/Off

WARRANTY

This warranty is valid only if original emporia batteries were used.
No warranty if battery door screwed incomplete.
Mobil phone: 12 month Battery: 6 month

SUPPORT

Emporia Service Center
Industriezeile 36 · 4020 Linz · Austria · www.emporia.at
Deutschland: 0049 (0)180 · 59 13 181
Österreich: 0043 (0)732 · 77 77 17 · 446
Schweiz: 0041 (0)8484 · 50004
DISPOSAL
Disposal of packaging:
Packaging and packaging materials are recyclable and should
always be returned.
Disposal of batteries:
Batteries must not be disposed of with domestic rubbish!
As a consumer you are required by law to recycle used batteries.
You may return them to your local collection point or to the dealer.
Disposal of the device:
Do not throw your mobile phone into the garbage, once it has
outlived its usefulness. For the benefit of the environment,
take it to a recycling location for used phones so it can be
processed in an environmentally responsible way.

DECLARATION OF CONFORMITY (DOC)

We, Emporia Telecom Produktions- und Vertriebs- GmbH & Co. KG. declare
under our sole responsibility that the following product is in conformity with
the following relevant harmonised standards.
Kind of product: Dual Band Mobile Phone
Article number: V33i
Governing EU-regulations: Council Directive R&TTE 1999/5/EC
Radio equipment and telecommunications terminal equipment
Harmonized EN standards:
Safety: EN 60950-1:2006 +A11:2009 + A1:2010
Health: EN 50360:2001
EMC: ETSI EN 301 489-1 V 1.8.1 (2008-04)
ETSI EN 301 489-3 V 1.4.1 (2002-08)
ETSI EN 301 489-7 V 1.3.1 (2005-11)
ETSI EN 301 489-17 V 2.1.1 (2009-05)
Radio spectrum: ETSI EN 300 328 V 1.7.1 (2006-10)
ETSI EN 300 220-2 V 2.3.1 (2012-02)
ETSI EN 300 440-2 V 1.4.1 (2010-08)
ETSI EN 301 511 V 9.0.2 (2003-03)
1313
Eveline Pupeter 01.04.2012, Linz/Austria
CEO

TECHNICAL PRODUCT DESCRIPTION

Dualband GSM 900/1800MHz Battery: Li-Ion 3.7V / 1750mAh
Internal antenna: SAR 0.799 W/kg Stand-by-time: 400 h (Applications,
Dimensions: 120 x 60 x 20 mm such as Bluetooth or GPS reduce the
Weight: 142 g operating time up to 80%.)

PACKAGE CONTENT

Mobil phone Charging cable
Battery: Li-Ion 3.7V / 1750mAh

CORRECT USAGE

This mobile phone is rugged and provided in accordance
with IP 67 for mobile use.
Do not expose it to direct sunlight.
Any utilization other than described above will cause damage
to the device, and may be hazardous (electric shock, fire, etc.).
The entire product must not be altered or rebuilt,
and the housing must not be opened.
The power plug is suitable only for use with residential-type
outlets of the public mains with 230 Volt/ 50 Hz (10/16A)
alternating current.

SAFETY INSTRUCTIONS

Switch off the mobile phone in hospitals or in the vicinity of medical
equipment, as the mobile phone may cause them to malfunction.
Keep your mobile phone a minimum distance of 20 cm away from
pacemakers, if it is turned on.
Never drive a car while holding the mobile phone in your hand.
Observe national law and traffic regulations governing the use
of mobile phones in traffic.
Always turn off your mobile phone inside an airplane.
You must switch off the mobile phone in the vicinity of petrol stations
and other places with explosive materials.
Don't shine the light directly into the eyes of people or animals.
If the speaker or headset is set to a high volume this can
cause hearing damage. Never hold the phone to your ear
when the speakerphone mode is activated or the emergency
button is pressed.
The device and its accessories may contain small parts.
Keep this product out of reach of small children.
As a precaution, we recommend disconnecting the charger
from the phone during a thunderstorm.
SOLIDplus
PartNo: V33i_[SW-V33i_V1.11]_ShortManual-V1A_54175-ENG_201208

INSERTING THE SIM CARD

Fig. 1a Fig. 1b
Fig. 1a+b: Remove the battery cover
Fig. 2: Insert the SIM card with the gold chip down

INSERT THE BATTERY AND CHARGING

Fig. 3 Fig. 4
Fig. 3: The battery contacts have to face the gold coloured
contacts of the mobile phone.
Fig. 4: Slide battery cover back to its previous position
until its locked with a click. Tighten the screws.
Fig. 5: open the rubber cover on the bottom of the phone
and plug the charging cable into the socket.
A battery icon on the display informs about the loading progress
Battery is charging: bars in the battery icon fi ll up
battery is fully charged: bars in the battery icon stop moving
Please note: The battery should be charged for at least 4 hours
before your first call. Use only batteries and chargers are
approved for use with this model.
Fig. 2
Fig. 5
