ELBRO SMSB242 User Manual

Sms switch butler
Hide thumbs Also See for SMSB242:
Table of Contents

Advertisement

Quick Links

Download this manual
User's manual
SMSB242/
SMSB482
SMS Switch Butler

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMSB242 and is the answer not in the manual?

Questions and answers

Related Manuals for ELBRO SMSB242

Summary of Contents for ELBRO SMSB242

  • Page 1 User's manual SMSB242/ SMSB482 SMS Switch Butler...

  • Page 3: Warning Notices

    The product has been tested on operating systems such as Windows 7, 8 and 10. Before installing the software, the User should take care to check the data tariff with their mobile service provider. Elbro will not accept liability under any circumstances for the costs charged by mobile telephone operators in cases of repeated sms transmissions or repeated GPRS data connections by the device.
  • Page 4 Comments  All information contained in this document can be changed without prior notification.  The duplication of this manual is, depending on the respective technology and means used for this purpose, both electroni- cally and physically, including photocopies or saving, are only permitted to the user for personal use and prohibited in all other cases without special written authorization.

  • Page 5: Safety Instructions

    For this reason the SMSB242/SMSB482 cannot be used with emergency call systems. Installation For the safety of the user and in order to ensure the fault-free operation of the SMSB242/SMSB482, the device may only be in- stalled by qualified experts. The specifications listed below must also be observed.
  • Page 6  Use the same voltage level for all relays: With high-voltage circuits, only the phase conductor may be connected via the re- lay contacts.
  • Page 7 Dimensions 30° 4,59 mm Interfaces SMSB482 ONLY GPRS Mo Tu We Th Fr Sa Su RE1 RE2 RE3 RE4 IN1 IN2 IN3 IN5 IN6 IN7 1. Relay outputs 2. SMA antenna connection (female) SMSB482 3. Mini-USB B port 4. Micro SD card slot 5.

  • Page 8: Wiring Diagram

    Wiring diagram Infeed, relay outputs and digital inputs SAMPLE ELECTRICAL CONNECTION For each relay, the output maximum current is 5A. Total sum must not exceed 10A at 250V~ SMSB482 LOAD1 LOAD2 LOAD3 LOAD4 NC COM NO NC COM NO NC COM NO NC COM NO 85÷265V~ RELAY 1...

  • Page 9: Relay Output Connection

    GSM network. This new system enables remote activation of up to four devices (up to two for SMSB242) and the monitoring of up to eight alarms (up to four for SMSB242) by means of simple SMS commands.

  • Page 10: Installing The Sim Card

    If a prepaid SIM card is used, the SMSB242/SMSB482 has a credit query function. We recommend activating this function in order to always remain informed of the current available credit.

  • Page 11: Software Description

    System status Figure 1: System status Synoptic: This panel displays the SMSB242/SMSB482 system status on the PC. Every device information is gathered here, such as the input status, output status, GSM signal level, etc.. Date/time: The system date can be updated in this screen; the system date is synchronized with the operating system (Windows).

  • Page 12: Sim Settings

    Butler to pre-defined e-mail users. However Elbro cannot guarantee the delivery of e-mails and is not responsible in case of disruptions. Elbro reserves the right cancel this free service to unilaterally at any time and with- out notice.

  • Page 13: Users List

    Users list Figure 2: List of users System password: In order to ensure the system safety, the device prompts the operator to enter a four-digit password to be able to send SMS commands. The default password is made up of four zeroes (0000). Please refer to the SMS commands section to get an overview of all available commands.

  • Page 14: Digital Inputs

    SMSB242/SMSB482 has eight alarm inputs (four for SMSB242), each of which allows sending to specific users an SMS when the contact is either opened or closed. The text is customizable for each event; the event can also be delayed in order to avoid false alarms (anti-bounce) and text messages can be sent sequentially.

  • Page 15: Analog Inputs

    Figure 4: Analogue inputs The SMSB242/SMSB482 has two analogue alarm inputs that can be configured in 0-10V, 0-20mA, PT100 and PT1000 with which text messages can be sent to a maximum of eight users when a threshold is exceeded. Two different thresholds can be set for each input.
  • Page 16 On this mask the message text for each relay can be individually configured. Response message: The relay can only be controlled by SMS commands. If you send a command to switch on or off the SMSB242/SMSB482 replies with an SMS message.

  • Page 17: Call Function

    Call function Figure 6: Call function The device is able to store a list of phone numbers with their relevant names (max 300) that are authorized to activate and/or deactivate the relay output 1 with a simple phone ring at no cost. The device detects the incoming call and immediately hangs up, activating at the same time the system it is connected to.
  • Page 18 Notifications Figure 7: Notification SMS Power failure notification: This feature allows selected users to receive a notification message when there is a power failure (power drop) and/or when power is restored. To perform this function, the device is equipped with two super-capacitors; they require at least 30 minutes charging before any SMS can be sent.

  • Page 19: Sms Commands

    SMS commands The SMSB242/SMSB482 can be configured and controlled through a command set that can be sent by sms. The command message is password protected (see chapter system password). The following is the command message format: [PASSWORD]#[COMMAND] for example: 0000#R1#1 (relay n.1 switch-on)

  • Page 20: Software Requirements

    Relay switching: 500mA 300mA Declaration of conformity ELBRO AG herein declares that the product SMSB242/SMSB482 complies with the essential requirements and with the other relevant provisions of Directive 199/5/EC, and specifically: EN 301 489-7 V1.1.1 (2000-09) EN 301 511 V7.0.1 (2000-12)

This manual is also suitable for:

Smsb482
