Description
Pressure Sensor
Pressure Range
Pressure Resolution
Pressure Calibrated
Accuracy
Humidity Sensor
Humidity Range
Humidity Resolution
Humidity Calibrated
Accuracy
Temperature Sensor
Temperature Range
-40 °C to +80 °C (-40 °F to +176 °F)
Temperature Resolution
Temperature Calibrated
Accuracy
688,128 readings; software configurable memory wrap
Memory
412,876 readings; (manual or trigger mode)
Reading Rate
1 reading every second to 1 reading every 24 hours
LED Indicator
Required Interface Package
Baud Rate
Typical Battery Life
10 year battery life typical, at a 15 minute reading rate
-40 °C to +80 °C, 0 %RH to 95 %RH non-condensing
Operating Environment
Material
Dimensions
Weight
Approvals
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT RECHARGE, DISASSEMBLE,
HEAT ABOVE 100 °C (212 °F), INCINERATE, CRUSH OR EXPOSE CONTENTS TO WATER.
Specifications subject to change.
See MadgeTech's terms and conditions at www.madgetech.com
MadgeTech, Inc.
6 Warner Road
Phone: (603) 456-2011
www.madgetech.com
PRHTemp101A
Piezoresistive
250 mbar to 1300 mbar
0.02 mbar
10 mbar
Capacitive Polymer
0 %RH to 95 %RH
0.1 %RH
3 %RH
RTD
0.01 °C
±0.5 °C
Red and green
IFC200
115,200
0.002 PSIA to 100 PSIA
ABS plastic
1.4 in x 2.2 in x 0.6 in
(36 mm x 56 mm x 16 mm)
0.9 oz (24 g)
CE
Warner, NH 03278
l
Fax: (603) 456-2012
l
info@madgetech.com
l
DOC-1278035-00 REV 1 2014.05.21
Product User Guide
PRHTemp101A
Pressure, Humidity & Temperature Data Logger
with a 10 Year Battery Life
PRHTemp101A
To view the full MadgeTech product line,
visit our website at
www.madgetech.com.
Advertisement
Table of Contents
Related Manuals for MadgeTech PRHTemp101A
Summary of Contents for MadgeTech PRHTemp101A
- Page 1 WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT RECHARGE, DISASSEMBLE, HEAT ABOVE 100 °C (212 °F), INCINERATE, CRUSH OR EXPOSE CONTENTS TO WATER. Specifications subject to change. See MadgeTech’s terms and conditions at www.madgetech.com MadgeTech, Inc. 6 Warner Road...
- Page 2 Programmable high and low limits; alarm is activated when the environment reaches or Recalibration exceeds set limits. (Pressure channel only) The PRHTemp101A standard calibration is one point for temperature at 25 °C, two Installation Guide points for humidity at 25 %RH and 75 %RH and two points for pressure at 460 mbar and 1095 mbar.
