- Page 1 XTLtouch Series Installation Guide...
-
Page 3: Table Of Contents
TABLE OF CONTENTS About the XTLtouch ....1 Accessories ......12 Transformer ......... 12 Install the XTLtouch ....2 Batteries ..........12 Wall Mount (XTLtouch) ....2 Desk Stand (XTLtouchUSB) ..2 Certifications ......13 Wall Mount ......3 FCC .........14 Mount the Backplate ......3 Industry Canada....16 Wire for Power ........ -
Page 4: About The Xtltouch
ABOUT THE XTLtouch™ The XTLtouch offers flexible features and functionality. It contains an XTLplus control panel with an integrated graphic touchscreen keypad, providing one device to control and operate a system. The XTLtouch has an LTE cellular communicator pre-installed for cellular use. The XTLtouch can be mounted to a wall or can be used for tabletop use. -
Page 5: Install The Xtltouch
INSTALL THE XTLtouch Wall Mount (XTLtouch) For wall mount installations, use the included backplate to mount the XTLtouch to a wall. Note: Install the XTLtouch near a wall outlet for the plug-in power supply. The power supply should be located within 100 feet of the XTLtouch using 22 AWG wire. -
Page 6: Wall Mount
WALL MOUNT Mount the Backplate Press the tab and remove the backplate from the XTLtouch. See Figure 3. Backplate Figure 3: Removing the Backplate Digital Monitoring Products | XTLtouch Installation Guide... - Page 7 Use the level and the included #6 screws to mount the backplate to the wall. See Figure 4 for mounting hole locations. Level Figure 4: Mounting Hole Locations Digital Monitoring Products | XTLtouch Installation Guide...
-
Page 8: Wire For Power
Wire for Power See Figure 5 for wire routing instructions before wiring the XTLtouch for power. Connect the XTLtouch +DC terminal to the positive terminal on the power supply. Connect the XTLtouch -DC terminal to the negative terminal on the power supply. - Page 9 Mounted Backplate Power Supply Figure 5: Routing Wires DC terminals DC terminals Digital Monitoring Products | XTLtouch Installation Guide...
- Page 10 Figure 6: Securing the XTLtouch with the Set Screw Digital Monitoring Products | XTLtouch Installation Guide...
-
Page 11: Desk Stand
DESK STAND Install the Desk Stand Legs Insert one leg into the holes in the back of the XTLtouch. Slide the leg upwards until the leg firmly snaps into place. Repeat steps 1 and 2 to install the other leg. See Figure 7. Figure 7: Connecting the Desk Stand Legs Digital Monitoring Products | XTLtouch Installation Guide... -
Page 12: Power The Xtltouch
Power the XTLtouch Plug the micro USB end of the cable into the back of the keypad. If desired, insert the cable into the strain relief to secure the XTLtouch to its power source. See Figure 8. Plug the other end of the cable into the transformer. Plug the power supply into a 120 VAC 60 Hz dedicated outlet not controlled by a switch. -
Page 13: Additional Information
ADDITIONAL INFORMATION SECONDARY POWER SUPPLY The XTLtouch’s 800 mAh rechargeable standby battery is used to provide four hours of battery power when DC power is not available. The battery is intended for back power only and should not operate the panel on a daily basis. If the battery is low or not plugged into the battery connector, a low battery condition is indicated by the panel. - Page 14 3.8 V 4800 mAh Rechargeable Battery (required for 24 hour standby) 3.8 V 800 mAh Rechargeable Battery Figure 9: Replacing the Battery Digital Monitoring Products | XTLtouch Installation Guide...
-
Page 15: Accessories
ACCESSORIES Transformer 372-500-W 12 VDC Nominal Power Supply (wall mount) 371-1000U-W Replacement 1 Amp USB Transformer and Cable (desk stand) Batteries XTLTOUCH4800/8 RPLCMNT 4800MAH BATT XTLTOUCH XTLTOUCH800/8 RPLCMNT 800MAH BATT XTLTOUCH Digital Monitoring Products | XTLtouch Installation Guide... -
Page 16: Certifications
CERTIFICATIONS FCC Wireless Receiver and Z-Wave Approvals FCC ID: CCKPC0199 IC: 5251A-PC0199 FCC Wi-Fi Network Approvals FCC ID: VW4-ATWINC1500 IC: 20266-WINC1500PB FCC LTE Cellular Communicators LTE FCC Part 15 ID: R17ME910C1NV Intertek (ETL) Listed ANSI/UL 985 Household Fire ANSI/UL 1023 Household Burglar ANSI/UL 1610 Central Station Burglar... -
Page 17: Fcc
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made by the user and not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 18 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Note: For listed residential fire and burglary applications, wire runs connected to the XTLtouch terminal block must remain in the same room within 98.5 feet (30 meters.)
-
Page 19: Industry Canada
INDUSTRY CANADA This device complies with Industry Canada Licence-exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. - Page 20 LT-1788 18373 © 2018 Digital Monitoring Products, Inc.
