Lu Interactive Playground UNO CONFIGURATION User Manual page 9

Operation
Calibration
Calibration will adjust the camera used to detect balls on the wall. Once the system is
calibrated, it is not necessary to repeat the operation each time. The system should only be
calibrated when you feel that the contact between the ball and the wall is not accurate. To
calibrate the system, follow the steps below:
1. Select the
2. Click on the
3. While the system is calibrating, a calibration grid will appear and after
a few seconds the message "Calibration Successful" will display.
4. Press "Esc" and "Enter" to return to the homepage.
5. Throw a ball into the white section to confirm that the contact of the
ball on the wall is now adjusted.
button in the setting menu.
button.
