Technical Specifications
INSTALLATION
POSITION*
SIZE
WEIGHT
RIGGING
POWER
CONSUMPTION
* Installation positions are optimal positions, but can be adapted to
different spaces when required. Contact us for more details.
d
d
d
d
d
d
d
CAMERA MODULE
16' (4.9m) from the wall
18' (5.5m) high
12'' L x 12'' L x 8'' H
30 x 30 x 20 (cm)
10 kg
33 lbs
1.5'' (3.8cm) pipe
mounting bracket
100-240V - 75W
LIGHT & SOUND
MODULE
18' (5.5m) from the wall
20' (6m) high
33'' L x 84'' L x 20'' H
84 x 213 x 50 (cm)
125 kg
275 lbs
4 Hanging Points
(+2 rig points for
installation)
100-240V - 1000W
PROJECTOR
MODULE
30' (9m) from the wall
18' (5.5m) high
22'' L x 20'' L x 10'' H
56 x 50 x 25 (cm)
25 kg
55 lbs
1.5'' (3.8cm) pipe
mounting bracket
100-240V - 462W
