MODEL 31-396
ir Motor Drive Unit
Includes the
following items:
3, 6, 8, 9, 23 and 24.
MODEL 31-397
Cover, gitator &
Drive ssembly
MODEL 41-3305
gitator ssembly only
(Less Items 6 & 22)
MODEL 31-400
gitator & Drive
ssembly
(Less Item 22)
20
20
ITEM
NO. P RT NO. DESCRIPTION
1
20-1237
SOC. HD. SET SCREW,
1/4-20 x 1/4" Lg ................................................
2
20-1741
SQ. HD. SET SCREW,
3*
20-1753
BUSHING,
1/4 NPT(F) x 3/8 NPT(M), (Not Shown)............
4
20-2077
HEX. HD. C P SCREW,
5/16-18 x 1-1/2" Lg., Stainless..........................
5
20-2079
HEX. NUT,
6
31-401
IR MOTOR DRIVE UNIT ................ 1
7
41-172
LOCK NUT ........................................ 1
8*
H-2008
D.M. NIPPLE
9*
H -57011 HOSE SSEMBLY,
1/4" I.D. x 13" Lg., (Not Shown )
10
83-1211
PIN .................................................... 1
11
83-2099
SH FT .............................................. 1
*FOR IR CONTROL WHEN REQUIRED.
Binks 55 G LLON
GE R DRIVEN DRUM COVER
6
24 23
22
4
5
2
BLOCK IS
19 18
HIDDEN
FROM VIEW
BLOCK IS
HIDDEN
19 18
FROM VIEW
4
5
P RTS LIST
When ordering, please specify Part No.
QTY.
1
2
Stainless ................
1
4
4
5/16-18, Stainless ......................
.................. 1
(Not Shown )
................ 1
GIT TOR UNITS
Stainless Steel Fitted
23 24
10
11
12
1
16
15
14
21
13
STUFFING
BOX
7
19
Read and follow all instructions and
S FETY PREC UTIONS listed on page 2
before using this equipment. Retain
for future reference.
19
2
ITEM
NO. P RT NO. DESCRIPTION
12
83-2107
BE RING SSEMBLY........................ 1
13
83-2109
BOX SSEMBLY .............................. 1
14
83-2110
W SHER .......................................... 1
15
83-2111
P CKING .......................................... 4
16
83-2112
GL ND ............................................ 1
17
83-2114
STUFFING BOX SSEMBLY .............. 1
18
83-2132
BLOCK .............................................. 2
19
83-2194
P DDLE ............................................ 4
20
83-2197
P DDLE SSEMBLY ........................ 2
21
83-3032
BE RING .......................................... 1
22
31-124
COVER SSEMBLY .......................... 1
23•
LOCK W SHER,
Purchase Locally
24•
HEX HD C P SCREW........................ 2
Purchase Locally
3/8-16 X 1" Lg Plated
•
Item Nos. 23 & 24 are included
with Item No. 6
ITEMS 13, 14, 15 AND 16
17
ARE ALSO INCLUDED
WITH ITEM 17
IMPORT NT
!
QTY.
.......................... 2
3/8
Replaces
Part
Part Sheet
Sheet
77-2804R-1
77-2804R-2
