ITEM
SHIMANO
DESCRIPTION
NO.
CODE NO.
Cable Adjusting Bolt & Nut
1
Y-8T6
98010
2
Y-8XV
98020
Reach Adjusting Screw (M4 x 14.5) & Spring
3
Y-8SB
10000
Clamp Bolt (M6 x 14.8)
A: Same parts.
B: Parts are usable, but differ in materirals, appearance, finish, size, etc.
Absence of mark indicates non-interchangeability.
DXR V-BRAKE Brake Lever
BL-MX70
1
2
2-Finger
3
INTERCHANGE-
ABILITY
A
A
B
0611-2660
