Planet Networking & Communication ICA-HM220W Quick Installation Manual

VERIFY THE CONTENTS INSIDE PACKAGE BOX
The package should contain the items plus ICA-HM220W. If any item is missing or damaged, please contact the seller immediately
Quick Installation Guide
Step 1 : Please follow the following instructions to set up the camera
Connect the Ethernet cable to your local area network,
å
and connect the other end to the LAN jack of this IP
camera.
Connect the antennas to the antenna base located at
é
the back of the IP camera.
Quick Guide
CD-ROM RJ-45 Antenna x 2 Power Adapter
Plug the power adapter to wall socket and connect the
ç
power connector to the power jack located at the back of
the IP camera.
Place the IP camera at a secure place, and point the
è
camera to the place you wish to monitor. If you wish to
hang the camera on the ceiling or wall, please use the
tripod connector (located at the bottom of the IP camera
as shown below) to secure the camera.
▼ : Locked position
ICA-HM220W
x 1
x 4 x 4
Camera Mounting Kit
Lock
