Instrument, IBT 100 for Torque Sensors. The specifications in this manual can change at any time without prior notification. Futek reserves the right to improve and to change the product for the purpose of technical progress without the obligation to inform persons and organizations as the result of such changes.
Page 6
We thank you for your decision to purchase a quality Futek product. Please read through this Operating Manual carefully in order to make best use of the versatile features of your product. This product is an IBT 100 Supply and Evaluation Instrument for Torque and Force Sensors.
Page 8
If hazard-free operation is no longer guaranteed as a result of the above-mentioned points, the instrument must be sent immediately to the responsible Futek Sales Company or representative for repair. The Supply and Evaluation Instrument, IBT 100 is designed to be CE-compliant.
Page 9
Keep this operation manual in a secure location where it is available at all times. If the manual is lost, please contact the responsible Futek Sales Company or representative and ask for a replacement. Instrument modifications (rebuilds, retrofits, etc.) normally also result in changes to the operation manual.
Page 10
Check all instrument packaging for damage in transit. Notify the shipping company and the responsible Futek Sales Company or representative of any such damage. Please check the shipment before beginning with the setup of the instrument system. If any part is missing, please contact the responsible Futek Sales Company or representative.
Page 11
There are two versions of the IBT100 listed below: Item# 105-125V Power FSH02121 210-250V Power FSH02426 The Supply and Evaluation Instrument, IBT 100 is supplied with: Item# AC Cord for Power Supply GOD 00682 Male DB9 connector with housing FSH 01075...
Page 12
IBT100, TRD300 TRD300 The TRD300 Series TRD300 TRH600 TRH600 TRH600 Series TRH600 Page 11...
Page 13
Architecture In the following the most important internal components of device architecture: Power Supply ± Page 12...
Page 14
These conditions can be set in the menu system. A new measured value storage operation overwrites the previously saved values. It is therefore only possible for a continuous measurement curve to be saved in the measured value buffer. UMV Software IBT100 Page 13...
Page 15
The operating keys and the backlit 4x20 character display of the Supply and Evaluation Instrument, IBT100 are on the front panel. All connection plugs and socket are mounted on the rear. Page 14...
Page 16
The Supply and Evaluation Instrument, IBT100 is suitable for integration in existing systems. The following figure shows a typical application of motor testing: The torque sensor can be supplied by the IBT 100 instrument. This results in electrical isolation between the...
Page 17
If the torque signal is to be used for control or regulation purposes, this can be carried out with the analog outputs of the Supply and Evaluation Instrument, IBT 100. This can be particularly advantageous with a passive sensor (mV/V signals) (works as a measured value amplifier). The speed recorded and measured by the IBT 100 instrument can be converted into a voltage parameter with an analog output.
Page 18
Description IBT 100 25-pin female D- Bridge supply +5V Sense + Bridge signal + Torque + (active sensor) −12V Counter 1 (zero pulse) GND (+5V) TXD * RXD * +12V Active control signal (TTL output for active sensors) +24V Bridge supply 0V Sense −...
Page 21
Digital input states, optocoupler An optocoupler is present on each digital input. The inputs are electrically isolated from the other parts of the circuits of the IBT 100, Supply and Evaluation Instrument. Logic state 1 or High: 3.5 V … 30 V. ≤...
Page 22
= +24 V (e.g. Pin 7 on IBT100) × × Page 21...
Page 24
The Supply and Evaluation Instrument, IBT 100 is operated from a menu. A total of 7 keys are provided for navigation. The main menu can always be selected with the MENU key. The Enter key ↵ is used to call up the submenu selected with the four arrow keys as well to confirm a change to a parameter.
Page 26
½ ½ ½ ¯ TRD305 § § § § IBT100 § § § § § Page 25...
Page 27
The IBT 100 instrument is parameterized in the ’Sensor’ menu using a connected torque or force sensor. Assignments between the output voltage/frequency and applied rated torque or rated force of a sensor are configured in this menu. When connecting a dual-range sensor, it is possible to define two nominal ranges of use (1st and 2nd range).
Page 28
If the ’Bridge’ measurement type is activated, the sensitivity of the strain gage bridge of a passive sensor × appears behind the abbreviation ’Sens.’. ± In conjunction with the selected ’Range’, the conversion of mV/V into the selected ’Unit’ of the sensor is carried out automatically.
